Оригинальный
номер |
Название |
Заказ |
| 1 |
5024307 |
Kit - Install - Uncontrld Catalyst to 15/5/1989 | OHC 2.0 EFI (115PS) Manual Transmi |
|
| 1 |
5024306 |
Kit - Install - Uncontrld Catalyst to 15/5/1989 | OHC 2.0H Manual Transmission D |
|
| 10 |
5015382 |
Tube Assy - Air Intake to 15/5/1989 | D |
|
| 11 |
6156119 |
Bracket - Exhaust Pipe Mounting to 15/5/1989 | D |
|
| 11A |
1613141 |
U-Bolt to 15/5/1989 | OHC 2.0H D |
|
| 11A |
6054346 |
U-Bolt to 15/5/1989 | 1.8L SOHC 8V Petrol D to 15/ |
|
| 11B |
1613142 |
Clamp to 15/5/1989 | OHC 2.0H D |
|
| 11B |
6054349 |
Clamp to 15/5/1989 | 1.8L SOHC 8V Petrol D to 15/ |
|
| 12 |
1591419 |
Insulator - Rubber to 15/5/1989 | D |
|
| 13 |
7131646 |
Insulator - Rubber to 15/5/1989 | D |
|
| 14 |
6835562 |
Pipe Assy - Filler to 15/5/1989 | D to 15/5/1989 | D |
|
| 15 |
6110379 |
Deflector - Air to 15/5/1989 | D |
|
| 16 |
5016555 |
Hose Assy to 15/5/1989 | D |
|
| 17 |
6061915 |
Strap - Wiring to 15/5/1989 | D |
|
| 18 |
6174739 |
Clip to 15/5/1989 | D to 15/5/1989 | D |
|
| 18A |
6743364 |
Clip to 15/5/1989 | D |
|
| 19 |
6159131 |
Clip to 15/5/1989 | D |
|
| 2 |
6879827 |
Pipe - Exhaust - Front to 15/5/1989 | D |
|
| 20 |
5016209 |
Spacer to 15/5/1989 | D |
|
| 21 |
6152142 |
Rivet - Expanding to 15/5/1989 | D |
|
| 22 |
1638509 |
Bolt - Hex.Head to 15/5/1989 | D |
|
| 23 |
6115062 |
Bolt - Hex.Head to 15/5/1989 | D |
|
| 24 |
6500001 |
Bolt - Hex.Head to 15/5/1989 | D |
|
| 24A |
7287256 |
Bolt - Hex.Head to 15/5/1989 | |
|
| 25 |
1027792 |
Washer - Flat to 15/5/1989 | D |
|
| 26 |
1652467 |
Nut - Hex. - Self-Locking to 15/5/1989 | D |
|
| 27 |
6503553 |
Nut - Hex. - Self-Locking to 15/5/1989 | D |
|
| 27A |
7287257 |
Nut - Hex. - Self-Locking to 15/5/1989 | |
|
| 28 |
5017376 |
Decal to 15/5/1989 | D |
|
| 28 |
6163510 |
Decal to 15/5/1989 | D |
|
| 29 |
5020058 |
Information Sheet to 15/5/1989 | D |
|
| 29 |
5024178 |
Information Sheet to 15/5/1989 | D |
|
| 3 |
6198413 |
Catalyst Assy to 15/5/1989 | D to 15/5/1989 | D to |
|
| 30 |
5021688 |
German "Tuev" Report to 15/5/1989 | D |
|
| 31 |
6170396 |
Wire Assy - Ignition to 15/5/1989 | |
|
| 32 |
6170394 |
Wire Assy - Ignition to 15/5/1989 | |
|
| 33 |
6170395 |
Wire Assy - Ignition to 15/5/1989 | |
|
| 34 |
6170397 |
Wire Assy - Ignition to 15/5/1989 | |
|
| 35 |
6545149 |
Kit - Repair to 15/5/1989 | |
|
| 36 |
6616584 |
Seal to 15/5/1989 | |
|
| 37 |
1640227 |
Spring - Pressure to 15/5/1989 | |
|
| 38 |
5099731 |
Spark Plug to 15/5/1989 | D |
|
| 38 |
5099732 |
Spark Plug to 15/5/1989 | D |
|
| 39 |
5024310 |
Fitting Instruction to 15/5/1989 | 1.8L SOHC 8V Petrol D to 15/ |
|
| 39 |
5024907 |
Fitting Instruction to 15/5/1989 | OHC 2.0H D |
|
| 4 |
5017597 |
Muffler Assy - Centre And Rear to 15/5/1989 | D |
|
| 40 |
5024905 |
National Type Approval to 15/5/1989 | OHC 2.0H D |
|
| 40 |
5024312 |
National Type Approval to 15/5/1989 | 1.8L SOHC 8V Petrol D to 15/ |
|
| 41 |
5024913 |
Connector - Pipe to 15/5/1989 | OHC 2.0H D |
|
| 42 |
1096825 |
Kit - Clamps to 15/5/1989 | |
|
| 42 |
1096826 |
Kit - Clamps to 15/5/1989 | |
|
| 4A |
1020060 |
Muffler Assy - Front to 15/5/1989 | |
|
| 4A |
6173059 |
Muffler Assy - Front to 15/5/1989 | D |
|
| 4B |
6183982 |
Muffler Assy - Rear to 15/5/1989 | 1.8L SOHC 8V Petrol D to 15/ |
|
| 5 |
6144095 |
Heat Shield to 15/5/1989 | D |
|
| 6 |
6134623 |
Gasket to 15/5/1989 | D |
|
| 7 |
6159188 |
Gasket to 15/5/1989 | D |
|
| 8 |
1514327 |
Plug to 15/5/1989 | D |
|
| 9 |
6044945 |
Screw - Adjusting to 15/5/1989 | D |
|
