Оригинальный
номер |
Название |
Заказ |
|
1H0199273A |
console front |
|
| (1) |
6K0199200D |
engine carrier with rubber mounting |
|
| (1) |
6K0199200E |
engine carrier with rubber mounting |
|
| (1) |
6K0199200C |
engine carrier with rubber mounting |
|
| (10) |
6K0199273A |
console front |
|
| (10) |
6K0199273 |
console front |
|
| (10) |
1H0199273J |
console front |
|
| (10) |
6K0199273B |
console front |
|
| (10) |
6K0199273E |
console front |
|
| (10) |
1H0199273C |
console front |
|
| (11) |
N 10048703 |
hexagonal head bolt M10X60 |
|
| (14) |
1H0199315AA |
sub-frame |
|
| (15) |
1H0199322J |
balance weight |
|
| (15) |
6K0199322 |
balance weight |
|
| (15) |
6K0199322C |
balance weight |
|
| (15) |
6K0199322B |
balance weight |
|
| (18) |
357199381C |
bonded rubber mounting rear |
|
| (18) |
357199402B |
bonded rubber mounting |
|
| (18) |
191199381A |
bonded rubber mounting rear |
|
| (2) |
1H0199233A |
bonded rubber mounting |
|
| (20) |
1H0199262E |
bonded rubber mounting right rear |
|
| (20) |
1H0199262A |
bonded rubber mounting right rear |
|
| (21) |
6K0199354B |
console right |
|
| (21) |
1H0199354H |
console right |
|
| (21) |
1H0199354L |
console right |
|
| (21) |
1H0199354K |
console right |
|
| (21) |
6K0199354 |
console right |
|
| (21) |
1H0199354J |
console right |
|
| (22) |
6K0199456 |
shield |
|
| (23) |
N 90335004 |
clamping washer 5X30 |
|
| (26) |
N 0195042 |
hexagon head bolt c/w shoulder M8X45B |
|
| (27) |
191199353D |
console left |
|
| (27) |
357199353A |
console left |
|
| (27) |
1H0199353D |
console left |
|
| (27) |
357199353B |
console left |
|
| (34) |
N 90553202 |
double stud with hexagon drive BM10X58/M8X12 |
|
| (6) |
1H0199609F |
bonded rubber mounting white |
|
| (6) |
1H0199609E |
bonded rubber mounting blue |
|
| (6) |
1H0199609B |
bonded rubber mounting |
|
| (6) |
1H0199609G |
bonded rubber mounting |
|
| (6) |
1H0199609J |
bonded rubber mounting |
|
| (9) |
N 10070403 |
hexagon head bolt c/w shoulder M10X30 |
|
| 15 |
1H0199322H |
balance weight |
|
| 16 |
N 10001204 |
hexagonal head bolt M8X55 |
|
| 17 |
N 90226403 |
shouldered hex. nut, self-locking M8 |
|
| 18 |
191199381A |
bonded rubber mounting rear |
|
| 19 |
N 0195334 |
hexagon head bolt c/w shoulder M8X20 |
|
| 2 |
191199233 |
bonded rubber mounting |
|
| 22 |
6K0199456A |
shield |
|
| 24 |
N 90553202 |
double stud with hexagon drive BM10X58/M8X12 |
|
| 25 |
N 10195301 |
hexagon head bolt c/w shoulder M8X35 |
|
| 28 |
N 10102803 |
hexagonal head bolt BM8X98-PC |
|
| 28 |
N 0195043 |
hexagonal head bolt BM8X45 |
|
| 29 |
N 0195033 |
hexagonal head bolt M8X35 |
|
| 2B |
357199501 |
balance weight |
|
| 2C |
N 10315601 |
hexagonal head bolt AM8X40 |
|
| 3 |
1H0199187A |
arm |
|
| 34 |
N 10241603 |
hexagon head bolt c/w shoulder AM10X45-SW16 |
|
| 35 |
N 10257501 |
hexagon head bolt c/w shoulder M10X24 |
|
| 4 |
1H0199175A |
washer 15X50X2,5 |
|
| 43 |
867129669 |
grommet |
|
| 44 |
1L0145349 |
sleeve |
|
| 45 |
6K0199717B |
dirt deflector |
|
| 5 |
N 10246501 |
hexagon head bolt c/w shoulder M10X62 |
|
| 9 |
N 10230201 |
shouldered bolt M10X32 |
|
