Оригинальный
номер |
Название |
Заказ |
| (1) |
028103351P |
cylinder head |
|
| (1) |
028103265HX |
cylinder head with valves and camshaft |
|
| (1) |
028103351M |
cylinder head |
|
| (1) |
028103265GX |
cylinder head with valves and camshaft |
|
| (1) |
028103351K |
cylinder head |
|
| (1) |
028103265JX |
cylinder head with valves and camshaft |
|
| (11) |
037103419B |
valve guide 36,5MM/7MM |
|
| (12) |
028103383BJ |
cylinder head gasket (metal) 1,57MM 2 holes |
|
| (12) |
028103383BH |
cylinder head gasket (metal) 1,53MM 1 hole |
|
| (12) |
028103383BR |
cylinder head gasket 1,61MM 3 holes |
|
| (12) |
028103383BQ |
cylinder head gasket 1,53MM 2 holes |
|
| (12) |
028103383BP |
cylinder head gasket 1,45MM 1 hole |
|
| (12) |
028103383BK |
cylinder head gasket (metal) 1,61MM 3 holes |
|
| (13) |
028103483G |
gasket |
|
| (14) |
028103469E |
cylinder head cover |
|
| (19) |
028103534A |
cover cap |
|
| (3) |
028103531B |
stud also use: M6X12 028 103 534 A |
|
| (30) |
028103935K |
covering |
|
| (30) |
028103935M |
covering |
|
| (4) |
N 0119191 |
locking cover oversize B25 |
|
| (9) |
N 0144083 |
stud CM10XM8X62 |
|
| - |
028103945A |
retainer |
|
| - |
028198012F |
gasket set for cylinder head |
|
| - |
028198012E |
gasket set for cylinder head |
|
| - |
867711532 |
retainer water hose |
|
| 10 |
068103384A |
cheese head bolt M12X115 |
|
| 13 |
028103483H |
gasket |
|
| 14 |
028103469L |
cylinder head cover |
|
| 15 |
028103532A |
sealing ferrule |
|
| 16 |
028103533 |
sealing washer |
|
| 17 |
028103536 |
concave washer |
|
| 18 |
N 90132603 |
hex. nut with washer M6 |
|
| 2 |
068103085E |
oil seal 47X10 |
|
| 20 |
06B103485B |
locking cover |
|
| 21 |
06A103483D |
gasket |
|
| 22 |
038103941E |
retainer |
|
| 23 |
N 01224110 |
spring washer B8X15X0,8 |
|
| 24 |
N 0102336 |
hexagonal head bolt M8X28 |
|
| 25 |
N 0103506 |
hexagonal head bolt M8X50 |
|
| 31 |
028103952 |
split rivet |
|
| 32 |
028103638 |
grommet |
|
| 33 |
028103638A |
grommet |
|
| 35 |
028103665 |
attachment bolt |
|
| 36 |
N 90132603 |
hex. nut with washer M6 |
|
| 37 |
028103937 |
cap |
|
| 39 |
021133287A |
seal |
|
| 4 |
N 0119142 |
locking cover 24 |
|
| 5 |
056103397 |
stud M8X56 |
|
| 6 |
N 01155811 |
washer 8,4X15X1,6 |
|
| 7 |
N 0110088 |
hexagonal nut M8 |
|
| 8 |
N 90188902 |
stud M8X35 |
|
| 9 |
N 90080301 |
stud M10X45 |
|
