Оригинальный
номер |
Название |
Заказ |
|
7H0883623A 9B9 |
satin black |
|
|
7H0885669A 01A |
schwarz |
|
|
7H0885939A 9B9 |
satin black |
|
|
7H0885063A 01A |
schwarz |
|
|
7H0885063B 01A |
schwarz |
|
|
7H0885663A 9B9 |
satin black |
|
|
7H0885939 9B9 |
satin black |
|
|
7H0883623B 9B9 |
satin black |
|
|
7H0883337A 9B9 |
satin black |
|
| (11) |
N 90666101 |
cable tie 4,5X200 |
|
| (12) |
7H0885461A |
pull loop backrest catch front |
|
| (2) |
N 0221464 |
hexagon nut, self-locking VM8 |
|
| (30) |
7H0885063B |
frame for rear seat |
|
| (31) |
N 0230038 |
shouldered hex. nut, self-locking F 7H-4H081 265>> F 7H-4X033 429>> AM8 |
|
| (31) |
N 91003901 |
socket head bolt with multi-point socket head F 7H-4H081 265>> F 7H-4X033 429>> M8X16 |
|
| (33) |
7H0883623B |
covering left lower |
|
| (34) |
7H0885939A |
belt lock guide right upper |
|
| 1 |
7H0885669A |
seat frame |
|
| 10 |
7H0886639 |
backrest catch |
|
| 12 |
7H0885461 |
pull loop backrest catch rear |
|
| 13 |
7H0885529 |
holder for bowden cable |
|
| 15 |
7H0885157 |
gas-filled strut |
|
| 16 |
701827439A |
ball pin |
|
| 17 |
443823397 |
clips |
|
| 2 |
N 10286102 |
shouldered hex. nut, self-locking M10 |
|
| 20 |
7H0885371 |
release lever |
|
| 21 |
N 90675501 |
lock washer 12 |
|
| 25 |
7H0885957 |
connecting rod |
|
| 26 |
7H0885227 |
clips |
|
| 28 |
7H0886843 |
pull loop |
|
| 3 |
7H0883389 |
interlock |
|
| 30 |
7H0885063A |
frame for rear seat |
|
| 31 |
N 91003901 |
socket head bolt with multi-point socket head F >> 7H-4H081 264 F >> 7H-4X033 428 M8X16 |
|
| 32 |
7H0883337A |
belt lock guide left upper |
|
| 33 |
7H0883623A |
covering left lower |
|
| 34 |
7H0885939 |
belt lock guide right upper |
|
| 35 |
7H0885663A |
covering right lower |
|
| 4 |
N 91003701 |
fillister hd. bolt . M10X50 |
|
| 5 |
N 91003601 |
fillister hd. bolt . M8X50 |
|
| 6 |
7H0883867 |
cover cap |
|
| 7 |
7H0883627 |
clip |
|
