Оригинальный
номер |
Название |
Заказ |
|
N 10251905 |
flat fuse 29/2x8 80-natural col |
|
| (24) |
357919754 |
flat contact housing connecting part switch 4 pin |
|
| (25) |
161937501B |
relay plate 9 pin |
|
| (28) |
357959968B |
flat contact housing with helper contact catch 6 pin |
|
| (3) |
N 90643701 |
cable tie with retainer for welded pin: 10X187 5 |
|
| (30) |
1H2971615C |
wiring conduit F 1E-T-000 001>> rhd |
|
| (30) |
1H1971615A |
wiring conduit F 1E-T-000 001>> lhd |
|
| (43) |
1J0972702 |
flat contact housing for single wiring: counterpart to: 2 pin 000 979 133 000 979 133 A 1J0 971 712 |
|
| (44) |
1H0972702 |
flat contact housing connecting part switches at pedal cluster 2 pin |
|
| (51) |
357972742 |
single wiring seal for wire cross section: 9,0X7,8 yellow 1,0 |
|
| (54) |
357972744A |
single wiring seal for wire cross section: 16,2X15,0 light blue 6,0 |
|
| (60) |
357972842 |
plug 9,0 black |
|
| (64) |
1H0973204A |
flat contact housing connecter location: 3 pin BW |
|
| (66) |
3A0973715 |
flat contact housing connecter location: 10 pin BV |
|
| - |
357972841 |
plug 5,6X7,8 green |
|
| 10 |
357903968 |
flat contact housing with helper contact catch connecter location: 10 pin F |
|
| 11 |
6N0973702 |
flat contact housing connecting part switch brake fluid 2 pin for: |
|
| 12 |
701906231 |
flat contact housing connecting part junction box hall sender 1 pin |
|
| 13 |
1H0906233 |
flat contact housing connecting part electric fan 3 pin |
|
| 14 |
037906240 |
flat contact housing connecting part exhaust recirculation wastegate by-pass air cut-off valve outer temperature sensor temperature sensor coupling piece switch for accelerator pedal 2 pin |
|
| 15 |
1H0906365 |
flat contact housing with gasket for single wiring: 68 pin 000 979 131 000 979 131 A 000 979 133 000 9 |
|
| 16 |
1H0906375 |
gasket 16X105 |
|
| 18 |
357906732A |
angled protective cap |
|
| 20 |
357972753 |
flat contact housing for single wiring: counterpart to: also use: 3 pin 000 979 126 000 979 126 A 000 979 217 357 97 |
|
| 21 |
191911261B |
control unit for glow plug for vehicles with glow plug heater |
|
| 22 |
357915971A |
flat terminal pin housing connecter location: 1 pin Z2 |
|
| 23 |
357915971B |
flat terminal pin housing connecter location: 1 pin 30,30B |
|
| 24 |
357915971C |
flat terminal pin housing connecter location: 1 pin Z1 |
|
| 25 |
3A0937501A |
fuse holder for fuse 2 pin N 102 519 05 |
|
| 27 |
357955968 |
flat contact housing with helper contact catch connecter location: 8 pin C |
|
| 28 |
357955968A |
flat contact housing with helper contact catch connecter location: 5 pin S |
|
| 29 |
1H0971615M |
wiring conduit connecting part water box |
|
| 29A |
028972335A |
clip connecting part injection pump |
|
| 3 |
N 90666101 |
cable tie 4,5X200 |
|
| 30 |
1H0971615S |
cable holder |
|
| 30A |
1H0971617B |
molded piece F 1E-T-000 001>> |
|
| 30B |
1H0971617C |
molded piece t-piece F 1E-T-000 001>> |
|
| 31 |
171971835A |
flat terminal pin housing connecting part wiper motor 5 pin |
|
| 32 |
1H0971840C |
grommet |
|
| 33 |
4B0971848 |
cable holder 20X28 |
|
| 35 |
4B0971848 |
cable holder |
|
| 36 |
1H0971905H |
grommet 39/5 |
|
| 37 |
1H0971905K |
grommet 39/12 |
|
| 38 |
357971967 |
flat contact housing with helper contact catch connecter location: 12 pin G1 |
|
| 39 |
357971967A |
flat contact housing with helper contact catch connecter location: 12 pin G2 |
|
| 40 |
357971968 |
flat contact housing with helper contact catch connecter location: 8 pin A2 |
|
| 41 |
357971968A |
flat contact housing with helper contact catch connecter location: 8 pin A1 |
|
| 42 |
161971988C |
flat connector housing connecting part heated spraying jet 2 pin |
|
| 43 |
191972701 |
flat terminal pin housing coupling piece for loom junction box hall sender 1 pin |
|
| 44 |
535972701 |
flat contact housing coupling piece wiring harness for dash panel 1 pin |
|
| 45 |
1J0972704 |
flat contact housing coupling piece wiring harness for steering column combination switch 4 pin |
|
| 46 |
191972713 |
flat connector housing coupling piece dash panel insert 3 pin |
|
| 47 |
1J0972732 |
flat terminal pin housing coupling piece wiring harness for headlight range control 4 pin |
|
| 48 |
357972740D |
single wiring seal for wire cross section: 3,9X7,8 grey 0,5-1,0 |
|
| 49 |
357972741 |
single wiring seal for wire cross section: 5,6X7,8 blue 1,0 |
|
| 5 |
N 90635517 |
corrugated pipe in coils of 5m order unit 5 4,5 |
|
| 50 |
357972741A |
single wiring seal for wire cross section: 5,6X7,8 red 1,5 |
|
| 51 |
357972741B |
single wiring seal for wire cross section: 5,6X7,8 yellow orange 2,5 |
|
| 53 |
357972742B |
single wiring seal for wire cross section: 9,0X7,8 red 2,5 |
|
| 54 |
357972742C |
single wiring seal for wire cross section: 9,0X7,8 green 4,0 |
|
| 56 |
357972752 |
flat contact housing connecting part turn signal pump switches on transmission coupling piece for compressor for loom alternator multi-function indicator 2 pin side |
|
| 57 |
357972753 |
flat contact housing connecting part speed sender for vehicles with glow plug heater control unit for glow plug 3 pin |
|
| 58 |
357972771 |
flat contact housing connecting part starter 1 pin |
|
| 59 |
4B0972840 |
plug 4,0X7,8 white |
|
| 6 |
N 90773501 |
corrugated pipe in coils of 5m order unit 5 10 |
|
| 60 |
357972841 |
plug 5,6X7,8 green |
|
| 62 |
3A0973103 |
flat connector housing coupling piece harness for engine compartment 24 pin |
|
| 63 |
1H0973103A |
round connector housing 15 pin |
|
| 64 |
1H0973203 |
flat contact housing connecting part thermal switch electric fan 3 pin |
|
| 65 |
3A0973713 |
flat contact housing connecting part air flow meter coupling piece switches at pedal cluster 6 pin |
|
| 66 |
3A0973734 |
flat contact housing coupling piece injection pump 8 pin |
|
| 67 |
N 01412811 |
fillister hd. bolt M5X8 |
|
| 68 |
N 0141387 |
fillister hd. bolt shorten to: M6X10 |
|
| 69 |
N 0171251 |
fuse B50 |
|
| 7 |
N 90773701 |
corrugated pipe in coils of 5m order unit 5 17 |
|
| 8 |
N 90773801 |
corrugated pipe in coils of 5m order unit 5 22 |
|
