Оригинальный
номер |
Название |
Заказ |
|
535885755B 4VY |
schwarz |
|
|
535885756B 8WY |
platinum |
|
|
535885756B 4VY |
schwarz |
|
|
535885755B 8WY |
platinum |
|
| (11) |
535885596A |
wire cable F 50-N-000 001>> right |
|
| (11) |
535885596 |
wire cable F >> 50-M-020 000 right |
|
| (11) |
535885595A |
wire cable F 50-N-000 001>> left |
|
| (17) |
535885705C |
backrest frame F 50-N-000 001>> left |
|
| (18) |
535885706C |
backrest frame F 50-N-000 001>> right |
|
| (20) |
535885755B |
rear panel trim left |
|
| (21) |
535885756B |
rear panel trim right |
|
| (22) |
535885775G |
padding for backrest left |
|
| (23) |
535885776E |
padding for backrest for vehicles with warning triangle right |
|
| (23) |
535885776J |
padding for backrest right |
|
| (3) |
535885471 |
locking hook left |
|
| (8) |
443885717 |
upholstery wire 2X480 |
|
| (9) |
531885539 |
guide bush F >> 50-M-020 000 |
|
| 1 |
171885167 |
bush for backrest |
|
| 11 |
535885595 |
wire cable F >> 50-M-020 000 left |
|
| 13 |
535885607 |
spring left |
|
| 14 |
535885608 |
spring right |
|
| 15 |
N 0124373 |
lock washer 7 |
|
| 16 |
191885683A |
pull rod |
|
| 17 |
535885705 |
backrest frame F >> 50-M-020 000 left |
|
| 18 |
535885706 |
backrest frame F >> 50-M-020 000 right |
|
| 19 |
191885747 |
collar |
|
| 2 |
171885169 |
pin for backrest |
|
| 22 |
535885775E |
padding for backrest left |
|
| 23 |
535885776F |
padding for backrest right |
|
| 26 |
N 01100624 |
hexagonal nut M6 |
|
| 27 |
N 01166615 |
washer 6,4X18X1,6 |
|
| 28 |
N 0122265 |
spring washer B6X12X0,5 |
|
| 3 |
535885472 |
locking hook right |
|
| 30 |
1H0886227 |
bearing bush |
|
| 31 |
N 90478201 |
fitted bolt M8X24 |
|
| 4 |
171885475 |
tension spring |
|
| 5 |
311881227 |
pin |
|
| 6 |
535885483B |
upholstery wire 2,8X520 |
|
| 8 |
N 90162606 |
upholstery wire 2,8X368 |
|
