Оригинальный
номер |
Название |
Заказ |
| (1) |
025971758C |
harness for elec. control unit F >> 24-K-175 000 |
|
| (1) |
025971758E |
harness for elec. control unit F 24-L-000 001>> |
|
| (11) |
037906240 |
flat contact housing connecting part throttle valve switch F >> 24-K-175 000 2 pin |
|
| (11) |
443906232 |
flat contact housing connecting part injector valve temperature sensor lambda probe 2 pin NTC heater |
|
| (11) |
443906233 |
flat contact housing connecting part throttle valve switch F 24-L-000 001>> 3 pin |
|
| (20) |
135937501A |
relay plate 9 pin |
|
| (21) |
141951253B |
relay F >> 24-K-175 000 F 24-L-000 001>> |
|
| (21) |
321919505A |
contact close relay F >> 24-K-175 000 |
|
| (23) |
357972752 |
flat contact housing connecting part pressure regulator for models with power steering also use: F 24-L-045 389>>* 2 pin 357 972 741 A |
|
| (29) |
357972741A |
single wiring seal for wire cross section: connecting part throttle valve switch F >> 24-K-175 000 5,6X7,8 red 1,5 |
|
| (29) |
191906102 |
protective cap connecting part throttle valve switch F 24-L-000 001>> |
|
| (30) |
443906236 |
flat contact housing 3 pin |
|
| (7) |
853945521 |
grommet 28X10,7 |
|
| (9) |
443906233 |
flat contact housing connecting part idling stabilsation 3 pin |
|
| 12 |
171906231B |
flat terminal pin housing 2 pin |
|
| 13 |
025906235B |
flat contact housing connecting part air flow meter 5 pin |
|
| 14 |
251906296A |
relay box |
|
| 15 |
251906306A |
cover |
|
| 16 |
251906309B |
gasket |
|
| 17 |
191906376A |
protective cap 20,5X11 |
|
| 18 |
251937501 |
relay plate 9 pin |
|
| 19 |
443937501B |
relay plate 9 pin |
|
| 2 |
N 0139681 |
oval head panel screw ST4,8X13-C |
|
| 22 |
251971905C |
grommet 52X16 |
|
| 23 |
211971921 |
angled connector housing connecting part pressure regulator F >> 24-L-045 388* 1 pin |
|
| 24 |
111971921B |
flat terminal pin housing 1 pin |
|
| 25 |
251971976 |
flat connector housing 2 pin |
|
| 26 |
161971976A |
flat connector housing 1 pin |
|
| 27 |
251971878C |
grommet 19/11,5 |
|
| 28 |
161971990A |
flat terminal pin housing 1 pin |
|
| 29 |
810972525 |
grommet 12,5X31 |
|
| 3 |
N 0154452 |
snap nut 4,8X16,5X11,5 |
|
| 4 |
N 90666101 |
cable tie 4,5X200 |
|
| 5 |
113809963 |
clamping washer |
|
| 6 |
022906102 |
protective cap 39X7,5 |
|
