Оригинальный
номер |
Название |
Заказ |
| (1) |
252971281 |
wiring harness for fresh air blower rhd |
|
| (1) |
251971284H |
series resistor 500W |
|
| (2) |
251971284K |
wiring harness for electric fan use if required: 171 971 934 |
|
| (3) |
251971280 |
bracket for resistance |
|
| (4) |
N 0139681 |
oval head panel screw ST4,8X13-C |
|
| (4) |
N 0138845 |
hexagon head panel screw 4,8X13 |
|
| (6) |
443971867 |
grommet 8,5 |
|
| - |
171971905B |
grommet 33,5/6 |
|
| - |
867919993 |
flat terminal pin housing 6,3 |
|
| - |
867972525B |
grommet thermal switch 26X13 3 pin |
|
| - |
253971565E |
wiring harness with resistance for fan motor evaporator F 24-H-000 001>> 24-H-175 000 F 24-J-000 001>> |
|
| - |
000971010 |
retaining plate for cable binder (self-adhesive) also use: 19X19MM N 020 902 2 |
|
| - |
256971281 |
wiring harness for additional heater in passeng. compartment F >> 24-F-175 000 F 24-G-000 001>> F 24-G-000 001>> 24-G-175 000 F 24-H-000 001>> rhd lhd lhd |
|
| 1 |
251971281 |
wiring harness for fresh air blower lhd |
|
| 1A |
251971284E |
series resistor for electric fan: 200/300W |
|
| 3 |
321971280 |
bracket for resistance |
|
| 5 |
251937501 |
relay plate |
|
| 7 |
171959999 |
flat terminal pin housing 6,3 |
|
