Оригинальный
номер |
Название |
Заказ |
|
2D0819869A B41 |
satin black |
|
|
2D0819869 B41 |
satin black |
|
|
2D0819869B B41 |
satin black |
|
|
2D0819869 B41 |
satin black |
|
| (18A) |
2D0819657 |
air duct for models with wheelbase: F 2D-3-020 502>> 3000MM |
|
| (18A) |
2D0819657 |
air duct for models with wheelbase: but without: floor cover for pass. compart. F 2D-3-020 502>> 3550MM-4000MM |
|
| (18B) |
2D0819657A |
air duct for models with wheelbase: with: floor covering and sound abs. F 2D-3-020 502>> 3550-4000MM |
|
| (37) |
2D0201901A |
fuel line F 2D-2-023 530>>* |
|
| (46) |
443133741A |
bonded rubber mounting |
|
| 1 |
311133343 |
pipe clip |
|
| 10 |
2D1261345A |
grommet |
|
| 11 |
2D1261481 |
holder for electr. contr. unit |
|
| 12 |
2D1261482 |
holder for electr. contr. unit |
|
| 13 |
7D0819597 |
pipe clip 26X16 |
|
| 14 |
2D1261800 |
pipe clip 34-15 |
|
| 15 |
2D1815209 |
retaining bracket F >> 2D-1-030 000* |
|
| 16 |
2D1819085 |
exhaust pipe |
|
| 17 |
701819100E |
fuel pump |
|
| 18 |
2D1819381 |
footwell vent F >> 2D-1-030 000* left |
|
| 18A |
2D0819869 |
air duct for models with wheelbase: but without: floor cover for pass. compart. F 2D-1-030 001>>*2D-3-020 501 3550-4000MM |
|
| 18A |
2D0819869 |
air duct for models with wheelbase: F 2D-1-030 001>>*2D-3-020 501 3000MM |
|
| 18B |
2D0819869A |
air duct for models with wheelbase: with: floor covering and insulation in passenger compartment F 2D-1-030 001>>*2D-3-020 501 3550-4000MM |
|
| 18C |
2D0819869B |
air duct for models with wheelbase: with: floor covering and insulation in passenger compartment F 2D-1-030 001>>* 3550-4000MM |
|
| 19 |
2D1819434 |
air distribution housing |
|
| 2 |
2D1261177 |
cover |
|
| 20 |
2D1819472 |
retainer |
|
| 21 |
2D1819758 |
sealing strip F >> 2D-1-030 000* |
|
| 22 |
2D1819791 |
gasket |
|
| 23 |
2D0963271 |
electronic control unit auxiliary heater |
|
| 24 |
2D0971543 |
wiring harness for auxiliary heater |
|
| 25 |
2D0971755 |
wiring harness for fuel pump |
|
| 26 |
N 01021612 |
hexagonal head bolt M6X18 |
|
| 27 |
N 01024016 |
hexagonal head bolt M8X20 |
|
| 28 |
N 01100517 |
hexagonal nut M5 |
|
| 29 |
N 01100627 |
hexagonal nut M6 |
|
| 3 |
2D1261213 |
outer panel |
|
| 30 |
N 0115227 |
washer A4,3X9X0,8 |
|
| 31 |
N 0122253 |
spring washer B5X11X0,5 |
|
| 32 |
N 0122265 |
spring washer B6X12X0,5 |
|
| 33 |
N 0139771 |
oval head panel screw B6,3X16 |
|
| 34 |
N 0141228 |
fillister hd. bolt M4X8 |
|
| 35 |
N 01412913 |
fill. hd. bolt, self locking M5X10 |
|
| 36 |
N 0201391 |
tube in coils of 5m order unit 5 4X1 |
|
| 37 |
N 0201505 |
tube in coils of 5m order unit 5 F >> 2D-2-023 529* 6X1 |
|
| 37 |
N 0201505 |
tube in coils of 5m order unit 5 6X1 |
|
| 38 |
N 0202821 |
hose in coils of 5m order unit 5 5X3 |
|
| 39 |
N 0202911 |
hose in coils of 5m order unit 5 3,5X3 |
|
| 4 |
2D1261214 |
outer panel for side panel front |
|
| 40 |
N 0209063 |
cable tie A6X450 |
|
| 41 |
N 0245083 |
pipe clip LA80-100 |
|
| 42 |
N 10408001 |
pop-rivet F >> 2D-1-030 000* 4X8 |
|
| 43 |
N 90030301 |
panel screw F >> 2D-1-030 000* B4,2X35 |
|
| 44 |
N 90597802 |
rivetted cap nut AM6/0,5-3 |
|
| 45 |
N 90775201 |
hose 90X1X300 |
|
| 47 |
2D1819065 |
gasket F 2D-1-030 001>>* 224X25X89 |
|
| 48 |
N 10501101 |
wood screw, button head F 2D-1-030 001>>* 6,0X45MM |
|
| 5 |
2D1261215 |
outer panel for side panel rear |
|
| 6 |
2D1261236 |
hose |
|
| 7 |
701261243 |
pipe clip 26-28MM |
|
| 8 |
2D1261317 |
sealing ring |
|
| 9 |
2D1261345 |
grommet |
|
