Оригинальный
номер |
Название |
Заказ |
|
N 90099601 |
hose in coils of 5m order unit 5 5,5X3 |
|
| (1) |
281261157D |
cover panel for vehicles with sliding door rhd left/right |
|
| (11) |
251201511G |
fuel filter |
|
| (2) |
293261157B |
cover panel for double cab |
|
| (2) |
281261157D |
cover panel for double cab |
|
| (2) |
281261157D |
cover panel for vehicles with sliding door rhd left/right |
|
| (2) |
282261157B |
cover panel rhd |
|
| (2) |
282261157B |
cover panel for models without sliding door lhd |
|
| (40) |
N 90666101 |
cable tie 4,5X200 |
|
| (4A) |
N 01152423 |
washer A6,4X12,5X1,6 |
|
| (5) |
N 0159461 |
hexagon head panel screw A6,5X19 |
|
| (50) |
7M0951253 |
relay |
|
| (54) |
281261491 |
fuel line |
|
| (9) |
N 01166615 |
washer 6,4X18X1,6 |
|
| - |
N 0201505 |
tube in coils of 5m order unit 5 6X1 |
|
| - |
N 90099601 |
hose in coils of 5m order unit 5 5,5X3 |
|
| - |
N 0202911 |
hose in coils of 5m order unit 5 3,5X3 |
|
| - |
N 0202911 |
hose in coils of 5m order unit 5 3,5X3 |
|
| - |
311963111D |
collar M14X1 |
|
| - |
411963209B |
safety switch |
|
| - |
N 0201505 |
tube in coils of 5m order unit 5 6X1 |
|
| - |
N 0202911 |
hose in coils of 5m order unit 5 3,5X3 |
|
| 1 |
281261157D |
cover panel lhd |
|
| 10 |
N 01100624 |
hexagonal nut M6 |
|
| 12 |
251261285A |
t-piece |
|
| 13 |
251261287 |
t-piece |
|
| 14 |
113127563 |
t-piece |
|
| 2 |
281261157D |
cover panel lhd |
|
| 23 |
111127537A |
terminal |
|
| 24 |
281261467B |
fuel pump 1 paint mark green |
|
| 25 |
281261467C |
fuel pump 1 paint mark DA 6 black |
|
| 26 |
281261467D |
fuel pump 1 paint mark white |
|
| 27 |
211261325A |
bonded rubber mounting |
|
| 29 |
411261679 |
pipe clip F >> 28-F-005 000 |
|
| 3 |
N 90529301 |
hexagonal head bolt M6X10 |
|
| 30 |
N 0122265 |
spring washer B6X12X0,5 |
|
| 30A |
N 01166615 |
washer 6,4X18X1,6 |
|
| 31 |
N 01100624 |
hexagonal nut M6 |
|
| 32 |
281261531 |
impulse damper |
|
| 34 |
311133343A |
clamp 9 |
|
| 35 |
411963201 |
ignition coil |
|
| 36 |
211963115A |
switch knob |
|
| 37 |
411963107C |
temperature regulator switch |
|
| 38 |
N 0177512 |
bulb W5/1,2W12V1,2W |
|
| 39 |
411963209B |
safety switch |
|
| 4 |
N 0122265 |
spring washer B6X12X0,5 |
|
| 41 |
N 0139705 |
oval head panel screw B4,8X9,5 |
|
| 42 |
N 0154581 |
snap nut B4,8X19X16 |
|
| 43 |
171937501 |
fuse box 2 point |
|
| 44 |
111945521 |
boot |
|
| 45 |
111945525 |
flat terminal pin housing 2 point |
|
| 48 |
531941845 |
relay plate 18 pin |
|
| 4A |
N 01166615 |
washer 6,4X18X1,6 |
|
| 5 |
N 01021527 |
hexagonal head bolt M6X15 |
|
| 50 |
211963135 |
relay |
|
| 51 |
251963271 |
electronic control unit |
|
| 52 |
N 0304001 |
rivetted cap nut M6/0,7-3-E |
|
| 54 |
283261493 |
hose for double cab shorten to: 1680MM |
|
| 55 |
N 90666101 |
cable tie 4,5X200 |
|
| 6 |
N 01152423 |
washer A6,4X12,5X1,6 |
|
| 7 |
N 01100624 |
hexagonal nut M6 |
|
| 8 |
443133741A |
bonded rubber mounting |
|
| 9 |
N 0122265 |
spring washer B6X12X0,5 |
|
