Оригинальный
номер |
Название |
Заказ |
|
701419669 01C |
satin black for steering wheel: 701 419 651 G |
|
|
701419651G 01C |
satin black |
|
|
281415669 01C |
satin black for steering wheel: 281 415 651 A |
|
| (10) |
291422561 |
steering column tube |
|
| (13) |
281415549 |
sheer bolt |
|
| (2) |
N 0103533 |
hexagonal head bolt M8X42 |
|
| (22) |
701419669 |
horn button |
|
| (24) |
N 90550002 |
shouldered hex. nut, self-locking BM16X1,5 |
|
| (4) |
N 01024416 |
hexagonal head bolt M8X30 |
|
| (9) |
291415497D |
steering tube 723 MM |
|
| (9A) |
291422501 |
steering tube |
|
| 1 |
211415409 |
flange for steering column |
|
| 10 |
281415561D |
steering column tube |
|
| 10 |
281415561D |
steering column tube |
|
| 11 |
N 01152520 |
washer A8,4X16X1,6 |
|
| 11A |
N 90033301 |
washer B8,4X20X2,5 |
|
| 12 |
N 01024118 |
hexagonal head bolt M8X22 |
|
| 13 |
N 0147392 |
allen key head bolt M8X16 |
|
| 14 |
N 0139771 |
oval head panel screw B6,3X16 |
|
| 15 |
N 0116672 |
washer B7,4X22X2 |
|
| 16 |
281863780 |
gasket for steering column |
|
| 17 |
281415603E |
kink strut |
|
| 18 |
171419341 |
support ring |
|
| 19 |
171419549 |
sleeve |
|
| 1A |
291415401A |
flange for steering column |
|
| 2 |
N 01034510 |
hexagonal head bolt M8X45 |
|
| 20 |
701419651G |
steering wheel |
|
| 21 |
321419661A |
return ring with slip ring 165MM |
|
| 22 |
281415669 |
cover cap |
|
| 23 |
271821890 |
clip |
|
| 26 |
281422417 |
universal joint |
|
| 27 |
N 0102706 |
hexagonal head bolt M8X40 |
|
| 28 |
N 0221464 |
hexagon nut, self-locking VM8 |
|
| 3 |
N 0221464 |
hexagon nut, self-locking VM8 |
|
| 4 |
N 0102478 |
hexagonal head bolt M8X35 |
|
| 4A |
291415539 |
pipe clip |
|
| 5 |
N 01224110 |
spring washer B8X15X0,8 |
|
| 6 |
N 0221464 |
hexagon nut, self-locking VM8 |
|
| 7 |
311199125 |
washer |
|
| 8 |
211415417 |
coupling |
|
| 9 |
281415497D |
steering tube 790 MM |
|
| 9A |
281422501A |
steering tube |
|
