Оригинальный
номер |
Название |
Заказ |
|
281881251 01C |
satin black |
|
|
281881478 01C |
satin black |
|
|
282881357 01C |
satin black |
|
|
281881359 01C |
satin black |
|
|
281881477 01C |
satin black |
|
|
281881357 01C |
satin black |
|
| (1) |
282881112C |
seat frame F >> 21-P-019 000 rhd |
|
| (1) |
282881112E |
seat frame F 21-P-020 001>> rhd |
|
| (11) |
281881122D |
carrier panel right |
|
| (12) |
282881295 |
stop buffer F >> 21-N-030 000* rear rhd |
|
| (15) |
282881357 |
retainer rhd |
|
| (19) |
282881265 |
bowden cable rhd |
|
| (24) |
N 0133371 |
spring sleeve 6X32 |
|
| (31) |
281881246 |
spring right |
|
| (33) |
282881149 |
angle rhd |
|
| (44) |
281881376A |
padding F 21-P-020 001>> |
|
| (46) |
281881478 |
cover cap right |
|
| - |
283881028A |
seat and backrest complete (without cover) F 21-P-020 001>> with: 2 seater right lhd POS. 1 |
|
| - |
283881028 |
seat and backrest complete (without cover) F >> 21-P-019 000 with: 2 seater right lhd POS. 1 |
|
| - |
N 0152611 |
clips 20X1,8 |
|
| 1 |
281881112F |
seat frame lhd |
|
| 10 |
N 01396626 |
oval head panel screw 4,2X13STC |
|
| 11 |
281881121A |
carrier panel left |
|
| 12 |
281881295A |
stop buffer F >> 21-N-300 000* rear lhd |
|
| 13 |
281881296 |
stop buffer F >> 21-N-030 000* front |
|
| 14 |
281881359 |
handle |
|
| 15 |
281881357 |
retainer lhd |
|
| 16 |
N 0133361 |
spring sleeve 6X26 |
|
| 17 |
N 0141395 |
fillister hd. bolt M6X12 |
|
| 19 |
281881265 |
bowden cable lhd |
|
| 2 |
N 0133001 |
spring sleeve 6X36 |
|
| 20 |
N 0111156 |
hexagonal nut BM5 |
|
| 21 |
281881261 |
lock |
|
| 22 |
N 0133371 |
spring sleeve 6X32 |
|
| 23 |
N 0147591 |
allen key head bolt M6X35 |
|
| 24 |
N 0432102 |
parallel dowel pin 5H8X40 |
|
| 25 |
N 0147591 |
allen key head bolt M6X35 |
|
| 26 |
N 01470210 |
allen key head bolt M6X15 |
|
| 27 |
281881249 |
connecting rod |
|
| 28 |
N 90157901 |
clamping washer B-10X21 |
|
| 29 |
281881224 |
locking lever |
|
| 3 |
281881141 |
angle |
|
| 30 |
281881251 |
knob |
|
| 31 |
281881245 |
spring left |
|
| 32 |
281881259 |
belt guide |
|
| 33 |
281881149 |
angle lhd |
|
| 34 |
111857799 |
hexagonal head bolt 7/16"X25 |
|
| 35 |
281881145 |
bearing bracket |
|
| 36 |
N 0147243 |
allen key head bolt M10X20 |
|
| 37 |
N 0147214 |
cheese head bolt M10X25 |
|
| 38 |
281881228 |
stop buffer |
|
| 39 |
N 90135401 |
pin 12H11X45X35 |
|
| 4 |
281881177 |
gas-filled strut |
|
| 40 |
N 0120113 |
spring ring A10 |
|
| 41 |
N 01101013 |
hexagonal nut M10 |
|
| 42 |
N 01023911 |
hexagonal head bolt M8X18 |
|
| 44 |
281881376 |
padding F >> 21-P-019 000 |
|
| 45 |
281881304A |
frame with spring core |
|
| 46 |
281881477 |
cover cap left |
|
| 5 |
N 90228201 |
rubber washer 8X2X16 |
|
| 6 |
N 01152520 |
washer A8,4X16X1,6 |
|
| 7 |
N 0124362 |
lock washer 6 |
|
| 8 |
N 0155283 |
securing arm S10 |
|
| 9 |
281881866 |
stop buffer |
|
