Оригинальный
номер |
Название |
Заказ |
|
253843196A 581 |
cloud white |
|
|
281843486A 041 |
schwarz |
|
|
282843485A 041 |
schwarz |
|
| (1) |
281843106G |
high sliding door with window opening use if required: right 251 843 502 A 251 843 508 A 211 843 604J/K 2 |
|
| (1) |
281843106D |
sliding door with window opening right |
|
| (1) |
281843106F |
high sliding door without window opening use if required: right 251 843 502A 251 843 508 A 211 843 604J/K 21 |
|
| (1) |
281843106C |
sliding door without window opening adapt with workshop equipment see catalogue: right 135 BT:67-20 |
|
| (1) |
282843105C |
sliding door with window opening left |
|
| (1) |
282843105B |
sliding door without window opening left |
|
| (14) |
214843367 |
guide piece left |
|
| (29) |
282843405 |
roller guide for sliding door left lower |
|
| (39) |
282843435 |
roller guide for sliding door left upper |
|
| (40) |
282843485A |
cover cap left |
|
| (47) |
282843743 |
stop for sliding door left |
|
| (5) |
282843335A |
hinge (complete) for sliding door left |
|
| (50) |
282843791 |
seal for sliding door left |
|
| (57) |
282843349 |
protective cap left |
|
| (58) |
282843389 |
protective cap left |
|
| (7) |
282843341 |
support for sliding door left |
|
| - |
281843107 |
repair plate - sliding door outer panel lower |
|
| - |
282843795A |
cover for side panel |
|
| - |
531807239 |
rubber washer |
|
| - |
282843795A |
cover for side panel |
|
| 1 |
281843106C |
sliding door without window opening right |
|
| 10 |
N 0110088 |
hexagonal nut M8 |
|
| 11 |
211843359B |
roller |
|
| 12 |
N 0120064 |
spring ring B6 |
|
| 13 |
N 0111165 |
hexagonal nut BM6 |
|
| 14 |
211843368 |
guide piece right |
|
| 15 |
N 0141453 |
fillister hd. bolt M6X30 |
|
| 16 |
N 01100624 |
hexagonal nut M6 |
|
| 17A |
251843371 |
operating cam |
|
| 18 |
211843373 |
pin for locking lever in hinge |
|
| 19 |
211843377A |
locking lever upper |
|
| 1A |
281843163 |
frame for sliding window |
|
| 2 |
253843196A |
beading |
|
| 20 |
211843379B |
locking lever lower |
|
| 21A |
251843381 |
leg spring left |
|
| 21B |
251843382 |
leg spring right |
|
| 22 |
N 0124362 |
lock washer 6 |
|
| 23 |
251843393 |
spring retainer |
|
| 24 |
211843395B |
tension spring |
|
| 25 |
N 90064901 |
lock washer 6 |
|
| 26 |
211805243 |
spring washer |
|
| 27 |
N 01021612 |
hexagonal head bolt M6X18 |
|
| 28 |
211721357A |
stop buffer |
|
| 29 |
281843406 |
roller guide for sliding door right lower |
|
| 3 |
281843312 |
stop buffer lower |
|
| 30 |
211843419 |
roller, upper |
|
| 31 |
211843425C |
guide roller lower |
|
| 32 |
N 0124071 |
securing ring 7X0,8 |
|
| 33 |
211843499 |
felt ring |
|
| 34 |
211843429 |
cover cap |
|
| 35 |
281843447 |
distance plate |
|
| 36 |
N 01167016 |
washer 8,4 |
|
| 37 |
N 01024416 |
hexagonal head bolt M8X30 |
|
| 38 |
211831701B |
oval head countersunk bolt |
|
| 39 |
281843436 |
roller guide for sliding door right upper |
|
| 4 |
281843314 |
stop buffer upper |
|
| 40 |
281843486A |
cover cap right |
|
| 41 |
211843423A |
guide roller upper |
|
| 42 |
281843441 |
pin |
|
| 43 |
N 01152520 |
washer A8,4X16X1,6 |
|
| 44 |
N 0110088 |
hexagonal nut M8 |
|
| 45 |
N 01414112 |
fillister hd. bolt M6X18 |
|
| 46 |
211805243 |
spring washer |
|
| 47 |
281843744 |
stop for sliding door right |
|
| 48 |
211843749 |
stop buffer |
|
| 49 |
N 01023911 |
hexagonal head bolt M8X18 |
|
| 5 |
281843336A |
hinge (complete) for sliding door right |
|
| 50 |
281843792 |
seal for sliding door right |
|
| 51 |
282843795A |
cover for side panel |
|
| 52 |
281843799 |
beading |
|
| 53 |
N 0139705 |
oval head panel screw B4,8X9,5 |
|
| 54 |
N 0116653 |
washer 5,3X15X1,6 |
|
| 55 |
281827285 |
staple for padlock |
|
| 56 |
281843821A |
covering |
|
| 57 |
281843350 |
protective cap right |
|
| 58 |
281843390 |
protective cap right |
|
| 60 |
N 90246901 |
washer 8,4X11X2 |
|
| 7 |
281843342 |
support for sliding door right |
|
| 8 |
281843351A |
u piece for sliding door hinge |
|
| 8A |
251843330 |
seal |
|
| 9A |
N 01155811 |
washer 8,4X15X1,6 |
|
