Оригинальный
номер |
Название |
Заказ |
| (1) |
281803115J |
longitudinal member left rear |
|
| (1) |
293803116Q |
longitudinal member for models with double cab and extended load platform wheelbase: right rear 2950MM |
|
| (1) |
291803116H |
longitudinal member right rear |
|
| (1) |
291803116H |
longitudinal member right rear |
|
| (1) |
291803116H |
longitudinal member right rear |
|
| (1) |
293803116Q |
longitudinal member right rear |
|
| (1) |
293803116Q |
longitudinal member right rear |
|
| (1) |
293803116Q |
longitudinal member for models with double cab right rear |
|
| (1) |
293803116Q |
longitudinal member for high roofed delivery van with high wing doors wheelbase: right rear 2950MM |
|
| (1) |
293803116Q |
longitudinal member right rear |
|
| (1) |
293803116Q |
longitudinal member right rear |
|
| (1) |
293803115Q |
longitudinal member for high roofed delivery van with high wing doors wheelbase: left rear 2950MM |
|
| (1) |
293803115Q |
longitudinal member for models with double cab left rear |
|
| (1) |
293803115Q |
longitudinal member left rear |
|
| (1) |
293803115Q |
longitudinal member for models with double cab left rear |
|
| (1) |
295803115N |
longitudinal member left rear |
|
| (1) |
295803115N |
longitudinal member left rear |
|
| (1) |
295803115N |
longitudinal member left rear |
|
| (1) |
293803115Q |
longitudinal member for models with double cab and extended load platform wheelbase: left rear 2950MM |
|
| (10) |
281803552J |
spring support right |
|
| (10) |
281803552J |
spring support F 28-G-000 001>>* right |
|
| (10) |
281803551J |
spring support left |
|
| (11) |
293803571A |
spring bush left |
|
| (11) |
291803572H |
spring bush for models with premissible total weight: for models with wheelbase: for models with double cab and permissible total weight: right 5000KG 3650MM 4500KG |
|
| (11) |
293803572A |
spring bush right |
|
| (11) |
293803572A |
spring bush right |
|
| (11) |
293803571A |
spring bush left |
|
| (13) |
283803653A |
bracket for tube, spare wheel mounting |
|
| (15) |
293803181T |
cross member f.propeller shaft |
|
| (15) |
293803181AC |
cross member f.propeller shaft wheelbase: 3650MM |
|
| (15) |
293803181T |
cross member f.propeller shaft for pick-up with extendes platform wheelbase: 2950MM |
|
| (15) |
293803181T |
cross member f.propeller shaft high-roofed delivery van with high wing doors wheelbase: F 28-K-000 001>> 2950MM |
|
| (2) |
293803103C |
side member upper part wheelbase: 2500MM |
|
| (2) |
293803104C |
side member upper part wheelbase: left 3650MM |
|
| (2) |
293803103C |
side member upper part for models with double cab |
|
| (2) |
293803103H |
side member upper part for models with premissible total weight: 5000KG |
|
| (2) |
293803103C |
side member upper part for models with double cab wheelbase: left 3650MM |
|
| (2) |
293803103H |
side member upper part for models with double cab and permissible total weight: 4500KG |
|
| (2) |
293803103C |
side member upper part wheelbase: 2950 MM |
|
| (2) |
293803103C |
side member upper part wheelbase: left 3650MM |
|
| (2) |
293803104C |
side member upper part wheelbase: right 3650MM |
|
| (2) |
293803103C |
side member upper part for models with double cab |
|
| (2) |
293803104B |
side member upper part for models with double cab |
|
| (2) |
293803103C |
side member upper part for models with double cab for models with double cab and extended load platform wheelbase: 2950MM |
|
| (2A) |
293803095C |
renforcement for side member upper part for models with double cab |
|
| (2A) |
293803095C |
renforcement for side member upper part for vehicles with extended load platform wheelbase: 2950MM |
|
| (2A) |
291803207A |
reinforcement for side member |
|
| (3) |
281883287 |
bracket f. bench seat mounting see illustration: 109-20 |
|
| (3A) |
281803137D |
support for models with double cab |
|
| (4) |
283803141B |
spring supp., upper part left |
|
| (4) |
283803142B |
spring supp., upper part right |
|
| (4) |
283803142B |
spring supp., upper part right |
|
| (4A) |
293803149C |
end section for side member upper part for models with double cab and permissible total weight: for models with double cab wheelbase: front 4500KG 3650MM |
|
| (4A) |
293803149C |
end section for side member upper part for models with premissible total weight: for models with wheelbase: front 5000KG 3650MM |
|
| (5) |
293803570 |
cross member for models with double cab and permissible total weight: rear 4500KG |
|
| (5) |
293803183 |
cross member for double cab with premissible total weight: for models with double cab wheelbase: rear 4500KG 3650MM |
|
| (5) |
283803181F |
cross member for models with double cab and permissible total weight: for models with double cab wheelbase: rear 4500KG 3650MM |
|
| (5) |
293803570 |
cross member for models with premissible total weight: rear 5000KG |
|
| (5) |
293803570 |
cross member for models with premissible total weight: rear 5000KG |
|
| (5) |
283803181F |
cross member for models with double cab also use: rear 293 803 571 A 293 803 572 A |
|
| (5) |
283803181H |
cross member for models with premissible total weight: for models with wheelbase: rear 5000KG 3650MM |
|
| (5) |
283803181H |
cross member rear |
|
| (5) |
281803181F |
cross member rear |
|
| (5) |
283803181F |
cross member for models with double cab rear |
|
| (5) |
291803181D |
cross member rear |
|
| (5) |
291803181C |
cross member rear |
|
| (5) |
291803181D |
cross member rear |
|
| (5) |
283803181H |
cross member also use: rear 293 803 571 A 293 803 572 A |
|
| (5A) |
171813175 |
bracket for exhaust silencer |
|
| (7) |
293803570 |
cross member |
|
| (8) |
291803197A |
cross member upper part rear, outer |
|
| (8A) |
281803273 |
cross support for models with double cab outer |
|
| (9) |
281803291A |
outrigger with bracket for muffler left |
|
| (9) |
293803292 |
outrigger with bracket for muffler for models with premissible total weight: for models with double cab and permissible total weight: for models with double cab wheelbase: 5000KG 4500KG 3650MM |
|
| (9) |
285803275A |
outrigger wheelbase: 3650MM |
|
| (9) |
285803296 |
outrigger for low-loader . right |
|
| - |
291399648 |
bearing bracket right rear |
|
| - |
291399614 |
bearing bracket right front |
|
| - |
291399613A |
bearing bracket left front |
|
| - |
281803265 |
support stabilizer front |
|
| - |
291253257 |
outrigger with bracket for muffler LT 45 4500KG |
|
| - |
291399647A |
bearing bracket left rear |
|
| - |
295803685A |
bearing bracket stabilizer rear |
|
| - |
293803571A |
spring bush left |
|
| - |
293803572A |
spring bush right |
|
| - |
293803572A |
spring bush right |
|
| - |
291253244 |
shield LT 45 (4500KG) |
|
| - |
N 90634901 |
pop-rivet A4X14 |
|
| - |
293803571A |
spring bush left |
|
| 1 |
293803115Q |
longitudinal member left rear |
|
| 10 |
281803551G |
spring support left |
|
| 11 |
281803571C |
spring bush |
|
| 12 |
281803592 |
mounting for panhard rod |
|
| 13 |
283803654 |
bracket for tube, spare wheel mounting |
|
| 14 |
293803816A |
mounting propeller shaft |
|
| 16 |
293803487 |
cover plate for cross member |
|
| 17 |
293801457B |
console wheelbase: 3650MM |
|
| 19A |
293803807A |
gusset plate for models with premissible total weight: for models with double cab and permissible total weight: 5000KG 4500KG |
|
| 2A |
293803095C |
renforcement for side member upper part |
|
| 3 |
283801457 |
console wheelbase: inner 2950MM |
|
| 3A |
281803137D |
support |
|
| 4 |
283803141B |
spring supp., upper part left |
|
| 4A |
283803149A |
end section for side member upper part front |
|
| 5 |
283803181H |
cross member rear |
|
| 5A |
281253463 |
bracket for exhaust silencer |
|
| 6 |
283803221 |
socket - jack |
|
| 7 |
283803191 |
cross member upper part rear center |
|
| 8 |
283803197 |
cross member upper part rear, outer |
|
| 8A |
281803273 |
cross support outer |
|
| 9 |
285803295 |
outrigger for low-loader . left |
|
