Оригинальный
номер |
Название |
Заказ |
| (1) |
600829051 |
headboard left a. right 2293MM |
|
| (1) |
293829051B |
headboard left a. right 3824MM |
|
| (1) |
293829051B |
headboard for models with double cab left a. right 3824MM |
|
| (1) |
283829051D |
headboard for models with double cab for vehicles with low loader pick-up left a. right 2589MM |
|
| (2) |
600829055 |
headboard rear 2192MM |
|
| (22) |
N 90003301 |
stop buffer A10X2 |
|
| (3) |
600829073 |
headboard front 2192MM |
|
| (3) |
285829073B |
headboard for vehicles with low loader pick-up front 2006MM |
|
| (4) |
N 01024022 |
bolt, hexagon head self-locking M8X20MK |
|
| (5) |
N 0122314 |
spring washer A10X18X0,8 |
|
| (5) |
N 0122293 |
spring washer A8X15X0,5 |
|
| (7A) |
293829346 |
step for tailboard F 28-J-000 001>> rear 2nd stage |
|
| (7A) |
293829345 |
step for tailboard F 28-J-000 001>> rear 1st stage |
|
| (8) |
707829361 |
hinge |
|
| (9) |
N 90054902 |
pin 12B11X67X64 |
|
| - |
261867097 |
stop buffer F 28-J-000 001>> |
|
| - |
261829577A |
stop buffer rework if necessary 30X40 |
|
| - |
803803583A |
plug 19 |
|
| - |
N 01152318 |
washer A5,3X10X1 |
|
| - |
N 0139713 |
oval head panel screw B4,8X22 |
|
| 1 |
283829051C |
headboard left a. right 3068MM |
|
| 10 |
N 0124111 |
securing ring 11X1 |
|
| 11 |
245829453 |
hook for dropside left front right rear |
|
| 12 |
245829454 |
hook for dropside right front left rear |
|
| 13 |
N 0141395 |
fillister hd. bolt M6X12 |
|
| 14 |
N 0115476 |
washer A6,5X14X1,6 |
|
| 15 |
283829459 |
latching eye rear |
|
| 16 |
N 0141395 |
fillister hd. bolt M6X12 |
|
| 17 |
N 0115476 |
washer A6,5X14X1,6 |
|
| 18 |
283829482 |
bracket for retaining cable left a. right |
|
| 19 |
283829481 |
bracket for retaining cable rear |
|
| 2 |
283829055B |
headboard rear 2006MM |
|
| 20 |
N 90437401 |
pop-rivet A4,8X10 |
|
| 21 |
283829491 |
retaining cable rear |
|
| 23 |
N 0200271 |
plug A15X1 |
|
| 24 |
N 90003301 |
stop buffer A10X2 |
|
| 25 |
211809507 |
plug |
|
| 3 |
283829073C |
headboard front 2008MM |
|
| 4 |
N 01025414 |
hexagonal head bolt M10X25 |
|
| 4 |
N 01023820 |
hexagonal head bolt M8X15 |
|
| 5 |
N 0122283 |
spring washer B8X17X0,8 |
|
| 5A |
N 01100830 |
hexagonal nut M8 |
|
| 6 |
283829315 |
flat cleat |
|
| 7 |
N 90437401 |
pop-rivet A4,8X10 |
|
| 7A |
7D5829345 |
step for tailboard rear |
|
| 7B |
N 90529301 |
hexagonal head bolt M6X10 |
|
| 7C |
N 01100624 |
hexagonal nut M6 |
|
| 8A |
245829397 |
stop buffer wheelbase: 3650MM |
|
