Оригинальный
номер |
Название |
Заказ |
|
281857797 01C |
satin black |
|
| (1) |
281809156 |
lower part for side panel right rear front |
|
| (10) |
282809181 |
side panel left rear lower |
|
| (11) |
291809199 |
outer panel for wheel housing left rear LT45 |
|
| (11) |
291809200 |
outer panel for wheel housing right rear LT45 |
|
| (12) |
282809260C |
b-pillar, inner right lower |
|
| (12) |
282809235D |
b-pillar, inner left lower |
|
| (12) |
281809260C |
b-pillar, inner right lower lhd |
|
| (13) |
282809237B |
b-pillar, inner left upper rhd |
|
| (13) |
282809238B |
b-pillar, inner right upper |
|
| (13) |
281809238B |
b-pillar, inner right upper lhd |
|
| (14) |
281809254A |
b-pillar, outer right |
|
| (15) |
282809294 |
lower part for side panel right front rhd |
|
| (16) |
282809349 |
d-pillar left rhd |
|
| (16) |
282809350 |
d-pillar right rhd |
|
| (16) |
281809350 |
d-pillar right lhd |
|
| (23) |
282809901 |
runner for sliding door left upper |
|
| (3) |
281843163 |
frame for sliding window |
|
| (7) |
281809176 |
lower part for side panel right rear rear |
|
| - |
281809184 |
clamping strip |
|
| - |
251863557 |
channel 1000MM |
|
| - |
291809249 |
intermediate panel LT45 |
|
| 1 |
281809155 |
lower part for side panel left rear front |
|
| 10 |
281809182 |
side panel right rear lower |
|
| 11 |
281809199 |
outer panel for wheel housing rear |
|
| 12 |
281809235D |
b-pillar, inner left lower |
|
| 13 |
281809237B |
b-pillar, inner left upper |
|
| 14 |
282809253A |
b-pillar, outer left |
|
| 15 |
281809293 |
lower part for side panel left front lhd |
|
| 16 |
281809349 |
d-pillar left lhd |
|
| 17 |
291809361 |
corner section for pillar d lower |
|
| 18 |
281809367 |
cover plate lower |
|
| 19 |
281809368 |
cover plate upper |
|
| 2 |
281809159A |
side panel with window opening left front lhd |
|
| 20 |
281809370 |
cover plate lower |
|
| 21 |
281809587A |
reinforcement inner |
|
| 22 |
281809587B |
reinforcement inner |
|
| 23 |
281809902 |
runner for sliding door see illustration: right upper 79-10 |
|
| 24 |
281857767 |
retaining rod for three-point seat belt on rear seat left outer |
|
| 25 |
281803729A |
threaded plate |
|
| 26 |
N 90529301 |
hexagonal head bolt M6X10 |
|
| 27 |
111857799 |
hexagonal head bolt 7/16"X25 |
|
| 28 |
111857707A |
washer |
|
| 29 |
281857797 |
cover cap |
|
| 3 |
281809917 |
window frame use if required: left front lhd 251 863 557 |
|
| 4 |
281809919 |
window frame left rear lhd |
|
| 5 |
281809920 |
window frame right rear lhd |
|
| 6 |
281809166 |
filler plate for side panel with guide for sliding door right |
|
| 7 |
281809175 |
lower part for side panel left rear rear |
|
| 8 |
281809179A |
side panel with window opening left rear lhd |
|
| 9 |
281809180A |
side panel with window opening right rear upper lhd |
|
