Оригинальный
номер |
Название |
Заказ |
|
171881253 01C |
satin black |
|
|
221881477 01C |
satin black |
|
|
251881253 01C |
satin black |
|
|
251881251 01C |
satin black |
|
|
251881478 01C |
satin black |
|
| (10) |
282881143 |
spring bar F >> 289 2600 000 rhd |
|
| (9) |
N 01470210 |
allen key head bolt F >> 289 2600 000 M6X15 |
|
| - |
281801365 |
reinforcement for safety belt attachment |
|
| 10 |
211881143 |
spring bar F >> 289 2600 000 lhd |
|
| 11 |
211881177 |
tension spring F >> 286 2501 755 F 286 2501 756>> lhd lhd rhd |
|
| 12 |
211881197 |
bush F >> 289 2600 000 lhd rhd |
|
| 13 |
211881209H |
slide rail F 287 2500 001>> left lhd left rhd |
|
| 14 |
211881210H |
slide rail F 287 2500 001>> right lhd right rhd |
|
| 15 |
N 0147018 |
allen key head bolt M6X12MK |
|
| 17 |
251881213 |
glide piece F 28A 0000 001>> lhd rhd |
|
| 19 |
211881219A |
locking lever F 287 2500 001>> lhd rhd |
|
| 20 |
211881228 |
pin F 286 2518 236>> lhd rhd |
|
| 22 |
211881247 |
leg spring F 286 2518 236>> lhd rhd |
|
| 23 |
251881243 |
leg spring F 28A 0000 001>> left |
|
| 24 |
251881244 |
leg spring F 28A 0000 001>> right |
|
| 25 |
171881253 |
handle |
|
| 25D |
251881253 |
handle F 28A 0000 001>> |
|
| 27 |
251881251 |
knob |
|
| 28 |
N 90022801 |
allen key head bolt F 287 2500 001>> 289 2600 000 M10X12 |
|
| 2A |
251881236 |
locking rod with grip |
|
| 30 |
251881303A |
seat well F 28A 0000 001>> left |
|
| 32 |
251881375 |
padding for seat F 28A 0000 001>> |
|
| 36 |
221881477 |
cover cap left |
|
| 37 |
251881478 |
cover cap right |
|
| 38 |
N 0152611 |
clips 20X1,8 |
|
| 9 |
N 0147591 |
allen key head bolt F 28A 0000 001>> M6X35 |
|
