Оригинальный
номер |
Название |
Заказ |
|
281805051D 043 |
grey black |
|
|
281805051E 043 |
grey black |
|
|
282805051D 043 |
grey black |
|
|
282805051F 043 |
grey black |
|
|
281805111 01C |
satin black |
|
|
251857627 01C |
satin black lhd |
|
| (1) |
281805035C |
front panel upper part F 21-P-019 501>>* also use: lhd lhd 281 805 037 A 281 805 041 E 281 805 053 D |
|
| (1) |
282805031L |
front panel F >> 21-P-019 500* rhd |
|
| (1) |
282805035C |
front panel upper part F 21-P-019 501>>* also use: rhd 281 805 037 A 281 805 041 E 281 805 053 D 281 |
|
| (13) |
282805253E |
cross member for front panel F 21-P-020 001>> rhd |
|
| (13) |
282805253C |
cross member for front panel F >> 21-P-019 000 rhd |
|
| (14) |
281805293D |
cross member for dashbord F 21-P-020 001>> |
|
| (17) |
282721081A |
bracket for pedal cluster rhd |
|
| (2) |
282805035C |
front panel upper part rhd |
|
| (3) |
281805037A |
front panel lower part F 21-P-020 001>> |
|
| (3) |
281805037 |
front panel lower part F >> 21-P-019 000 |
|
| (4) |
281805041E |
deformation element F 21-P-020 001>> use if required: 281 805 748A/B |
|
| (5) |
282805051D |
dashboard rhd |
|
| (5) |
282805051F |
dashboard rhd |
|
| (5) |
281805051E |
dashboard lhd |
|
| - |
281806163 |
angle F 21-P-020 001>>* |
|
| - |
281805157 |
tab F 21-P-020 001>>* |
|
| - |
281805748B |
retainer |
|
| - |
281805155 |
retainer bracket F 21-P-020 001>>* |
|
| - |
283805485B |
rear panel chassis with cab lower |
|
| - |
281805748A |
retainer |
|
| - |
N 90801201 |
t-bolt 3X7,1 |
|
| 1 |
281805031R |
front panel F >> 21-P-019 500* lhd |
|
| 10 |
281805053D |
side panel left front |
|
| 11 |
281805054D |
side panel right front |
|
| 12 |
281805111 |
cover for brake fluid container |
|
| 13 |
281805253D |
cross member for front panel lhd |
|
| 14 |
281805293C |
cross member for dashbord F >> 21-P-019 000 |
|
| 15 |
283805425A |
cab panel, rear, outer |
|
| 16 |
283805429A |
cab panel, rear, inner |
|
| 17 |
281721081B |
bracket for pedal cluster lhd |
|
| 18 |
251857627 |
plug rhd |
|
| 2 |
281805035C |
front panel upper part lhd |
|
| 4 |
281805041C |
deformation element F >> 21-P-019 000 |
|
| 5 |
281805051D |
dashboard lhd |
|
| 6 |
N 0139655 |
oval head panel screw B4,2X9,5 |
|
| 7 |
N 0116653 |
washer 5,3X15X1,6 |
|
| 8 |
N 0141395 |
fillister hd. bolt M6X12 |
|
| 9 |
211805243 |
spring washer |
|
