Оригинальный
номер |
Название |
Заказ |
| (1) |
2D1827091D |
wing door without window opening left |
|
| (1) |
2D1827091E |
high wing door without window opening left |
|
| (1) |
2D1827091G |
high wing door with window opening left |
|
| (16) |
2D1827585 |
distance piece check rod - door for wing doors with opening angle: F >> 2D-V-016 900* 270 degrees |
|
| (18) |
2D1827605A |
retaining panel for wing doors with opening angle: F 2D-2-000 001>> 270 degrees |
|
| (19) |
2D1827793B |
check rod - door for wing doors with opening angle: 270 degrees |
|
| (2) |
2D1827092 |
wing door without window opening right |
|
| (2) |
2D1827092B |
high wing door without window opening right |
|
| (2) |
2D1827092C |
high wing door with window opening right |
|
| (20) |
N 10413401 |
torx socket fillister hd. bolt for wing doors with opening angle: M6X25-E 270 degrees |
|
| (27) |
2D1827845C |
gasket for high wing door center |
|
| (3) |
2D1827787A |
reinforcement stop for side panel for wing doors with opening angle: for models with wheelbase: 270 degrees 4025MM |
|
| - |
AKL44803005 |
protective foil 0,03X5M transparent |
|
| - |
701827157D |
gasket 210X149MM |
|
| - |
323863950 |
sound absorber (self-adhesive) order unit 6 550X250X2 |
|
| 1 |
2D1827091F |
wing door with window opening left |
|
| 10 |
2D1827341 |
base for wing doors with opening angle: 270 degrees |
|
| 11 |
2D1827455 |
stop mounting check rod - door |
|
| 12 |
N 90478601 |
pop-rivet A4,8X11X9,5 |
|
| 13 |
2D1827475 |
magnet check rod - door for wing doors with opening angle: 270 degrees |
|
| 14 |
N 10412203 |
cheese head bolt M5X35 |
|
| 15 |
2D1827489 |
stop buffer |
|
| 16 |
2D1827549 |
distance piece for wing doors with opening angle: for models with premissible total weight: 270 degrees 4600KG |
|
| 17 |
2D1827601 |
retainer for wing doors with opening angle: 270 degrees |
|
| 18 |
2D1827605 |
retaining panel for wing doors with opening angle: F >> 2D-1-040 000 270 degrees |
|
| 19 |
2D1827793A |
check rod - door |
|
| 2 |
2D1827092A |
wing door with window opening right |
|
| 20 |
N 10405601 |
torx socket fillister hd. bolt M6X14-E |
|
| 21 |
2D1827797 |
stop for side panel for wing doors with opening angle: 270 degrees |
|
| 22 |
2D0857168 |
lock nut |
|
| 23 |
N 90744501 |
bolt, torx socket head M8X16 |
|
| 24 |
2D1827035A |
insert piece for wing doors with opening angle: 270 degrees 2D1 827 605 A |
|
| 25 |
N 10423401 |
split pin F >> 2D-1-040 000 2,5X28 |
|
| 26 |
N 90734601 |
rivetted cap nut M5/0,25-1 |
|
| 27 |
2D1827845B |
gasket center |
|
| 28 |
2D1829193E |
gasket shorten if necessary F 2D-3-021 571>> rear |
|
| 28 |
2D1829193C |
gasket shorten if necessary F >> 2D-3-021 570 rear |
|
| 3 |
2D1827111 |
reinforcement stop for side panel for models with wheelbase: for wing doors with opening angle: 3000/3550MM 270 degrees |
|
| 4 |
2D1827151 |
door hinge left/right |
|
| 5 |
2D1827151A |
door hinge for wing doors with opening angle: left/right 270 degrees |
|
| 6 |
N 0147392 |
allen key head bolt M8X16 |
|
| 7 |
N 0447041 |
allen key head bolt M8X28 |
|
| 8 |
N 90751501 |
torx socket fillister hd. bolt M8X25 |
|
| 9 |
2D1827194 |
securing plate check rod - door |
|
