Оригинальный
номер |
Название |
Заказ |
| (1) |
038103265MX |
cylinder head with valves, camshaft and injector (pump/jet) |
|
| (16) |
038103383CJ |
cylinder head gasket 1,51MM 2 holes |
|
| (16) |
038103383BM |
cylinder head gasket 1,53MM 2 holes |
|
| (16) |
038103383CK |
cylinder head gasket 1,61MM 3 holes |
|
| (16) |
038103383BN |
cylinder head gasket 1,61MM 3 holes |
|
| (16) |
038103383BL |
cylinder head gasket 1,45MM 1 hole |
|
| (21) |
038103469S |
cylinder head cover |
|
| (28) |
03G103941N |
retainer front |
|
| (28) |
03G103941M |
retainer front |
|
| (32) |
038103493AC |
breather tube |
|
| (5) |
N 0119191 |
locking cover B25 |
|
| 1 |
038103351D |
cylinder head |
|
| 10 |
N 0256663 |
ball 8V |
|
| 11 |
044103499B |
connecting socket |
|
| 14 |
038103385A |
cheese head bolt M6X64 |
|
| 15 |
038130085 |
emulsion tube |
|
| 16 |
038103383CH |
cylinder head gasket 1,41MM 1 hole |
|
| 17 |
038103384 |
cheese head bolt M12X166 |
|
| 2 |
038103085C |
shaft oil seal (shaft rotation: to right) 47X10 |
|
| 21 |
038103469AC |
cylinder head cover |
|
| 24 |
021103831 |
bolt, hex. hd. with shoulder and sleeve M6 |
|
| 25 |
06B103485B |
locking cover |
|
| 26 |
06A103483D |
gasket |
|
| 29 |
N 0102336 |
hexagonal head bolt M8X28 |
|
| 3 |
N 0138115 |
seal A10X13,5 |
|
| 30 |
03G103369A |
lifting bracket rear |
|
| 31 |
N 10239402 |
hexagon socket head bolt with collar M8X22 |
|
| 32 |
038103493AK |
breather tube |
|
| 33 |
N 90687001 |
spring-type clip B27X12 |
|
| 4 |
N 0160241 |
sealing plug M10X1 |
|
| 5 |
N 0119142 |
locking cover 24 |
|
| 6 |
N 90115702 |
washer 12,5X23,5X4,5 |
|
| 7 |
038103714 |
fitted bolt M6X54 |
|
| 8 |
N 90188902 |
stud M8X35 |
|
| 9 |
N 90905502 |
stud CM10AXM8X73 |
|
