Оригинальный
номер |
Название |
Заказ |
|
8D0877792A 01C |
satin black |
|
|
8D0877255D 5PL |
light beige |
|
|
8D0877255D X09 |
pearl grey -AH,AJ,CM,CR, DE,DF,DK,DL, FP,FU,HT,HU, JE,JJ,JL,L |
|
|
8D0877793A 01C |
satin black |
|
|
8D0877794A 01C |
satin black |
|
|
8D0877782B 01C |
satin black |
|
|
1J0877829A 2PK |
light beige -AM,CZ,FZ,HW, JA,RG,RY,VH, VP,VW |
|
|
8D0877781B 01C |
satin black |
|
|
1J0877829A 2XP |
pearl grey -AH,AJ,CM,CR, DE,DF,DK,DL, FP,FU,HT,HU, JE,JJ,JL,L |
|
|
8D0877791A 01C |
satin black |
|
| (27) |
1J0877829A |
cover for electric drive |
|
| (30) |
1J6877234A |
water drain hose right rear |
|
| (30) |
1J6877233A |
water drain hose left rear |
|
| (31) |
1J6877244 |
terminal water drain hose upper |
|
| (31) |
1H0877244 |
clip center |
|
| (34) |
8D5877482 |
guide locking segment right |
|
| (38) |
8D5877152 |
gate guide right |
|
| (4) |
8D0877255D |
frame for sliding roof opening with cover |
|
| (40) |
8D5877484 |
guide right front |
|
| (5) |
4B0877165 |
glide piece to be used for: 8D0 877 255 D |
|
| (5) |
8D5877165A |
guide piece with screw,csk.hd. order unit 4 |
|
| (7) |
8D0877792A |
trim right upper |
|
| (8) |
8D0877794A |
trim right lower |
|
| - |
8D0877781B |
bellows left |
|
| - |
8D0877782B |
bellows right |
|
| 1 |
8D0877071C |
glass sliding roof panel also use: 8D0 877 781 B 8D0 877 782 B (01C) |
|
| 10 |
8D0877633B |
water channel |
|
| 11 |
G 00045002 |
grease 90G |
|
| 13 |
AKL45000505 |
butyl adhesive / sealing cord adhesives and sealing compound 5X5000 |
|
| 14 |
8D5898200 |
1 set of ball end piece left/right rear |
|
| 16 |
8D5877049A |
frame with operating mechanism |
|
| 18 |
8D5877655 |
wind deflector |
|
| 19 |
8D5898671 |
1 set: mounting f. wind defle. left/right |
|
| 2 |
8D0877297D |
gasket 2425MM |
|
| 20 |
8D5898652 |
1 set: rubber stop |
|
| 21 |
8D5877975 |
leaf spring wind deflector |
|
| 22 |
N 90749801 |
torx socket fillister hd. bolt M6X12 |
|
| 23 |
8D5877721 |
bolt, torx socket head |
|
| 24 |
8D5877479 |
washer |
|
| 26 |
895877849 |
crank for winding gear |
|
| 29 |
N 90884801 |
torx socket fillister hd. bolt M5X18 |
|
| 3 |
6N0877721 |
torx socket cheese head bolt (combi) order unit 4 F. BEFESTIGUNG GLASDECKEL M5X16 |
|
| 30 |
1J0877231A |
water drain hose front |
|
| 32 |
1J0877242 |
drain tube |
|
| 34 |
8D5877481 |
guide locking segment left |
|
| 37 |
8D5877421 |
distance piece |
|
| 38 |
8D5877151 |
gate guide left |
|
| 40 |
8D5877483 |
guide left front |
|
| 41 |
8D5898015 |
guide with cable left/right |
|
| 7 |
8D0877791A |
trim left upper |
|
| 8 |
8D0877793A |
trim left lower |
|
