Оригинальный
номер |
Название |
Заказ |
| (10) |
02J311247D |
synchronizer ring also use: 1./2.gear >>G 01 083 02J 311 277 B |
|
| (10B) |
02J311277B |
synchronizer ring inner also use: 1./2.gear >>G 01 083 02J 311 247 D |
|
| (16) |
02J311247D |
synchronizer ring also use: 1./2.gear >>G 01 083 02J 311 277 B |
|
| (18) |
02J311277B |
synchronizer ring inner also use: 1./2.gear >>G 01 083 02J 311 247 D |
|
| (19) |
02J311261J |
change gear 2.gear 36/17 |
|
| (2) |
020311391M |
adjusting washer 1,35 |
|
| (2) |
020311391N |
adjusting washer 1,4 |
|
| (2) |
020311391Q |
adjusting washer 0,7 |
|
| (2) |
020311391P |
adjusting washer 0,65 |
|
| (2) |
020311391L |
adjusting washer 1,3 |
|
| (2) |
020311391K |
adjusting washer 1,25 |
|
| (2) |
020311391J |
adjusting washer 1,2 |
|
| (2) |
020311391A |
adjusting washer 0,8 |
|
| (2) |
020311391B |
adjusting washer 0,85 |
|
| (2) |
020311391C |
adjusting washer 0,9 |
|
| (2) |
020311391D |
adjusting washer 0,95 |
|
| (2) |
020311391E |
adjusting washer 1 |
|
| (2) |
020311391H |
adjusting washer 1,15 |
|
| (2) |
020311391G |
adjusting washer 1,1 |
|
| (2) |
020311391F |
adjusting washer 1,05 |
|
| (22) |
02A311129AA |
change gear 3.gear 34/25 |
|
| (22) |
02A311129AH |
change gear 3.gear Z=31/23 |
|
| (22) |
02A311129T |
change gear 3.gear 35/24 |
|
| (24) |
02J311301B |
synchronizing hub with locking collar also use: 3./4.gear 02J 311 269 E |
|
| (27) |
02A311145L |
change gear 4-speed Z=29/30 |
|
| (27) |
02A311145N |
change gear 4-speed Z=35/34 |
|
| (27) |
02A311145AH |
change gear 4-speed 36/33 |
|
| (30) |
02A311361N |
gear 5-speed 30/39 |
|
| (30) |
02A311361AS |
gear 5-speed 37/42 |
|
| (8) |
02Z311251A |
change gear G 28 01 4>> 1.gear Z=34 |
|
| 10 |
02J311247C |
synchronizer ring G >> 31 07 3 1.gear |
|
| 10A |
02J311279 |
outer ring 1.gear |
|
| 10B |
02J311277A |
synchronizer ring inner G >> 31 07 3 1.gear |
|
| 11 |
02J311239J |
synchronizing hub with locking collar 1./2.gear |
|
| 12 |
084311313 |
locking piece |
|
| 13 |
02F311336 |
spring 1./2.gear |
|
| 14 |
091311321A |
securing ring |
|
| 15 |
02A311265D |
needle cage K35X40X23,8 |
|
| 16 |
02J311247C |
synchronizer ring G >> 31 07 3 2.gear |
|
| 17 |
02J311279 |
outer ring 2.gear |
|
| 18 |
02J311277A |
synchronizer ring inner G >> 31 07 3 2.gear |
|
| 19 |
02J311261G |
change gear 2.gear 33/16 |
|
| 2 |
020311391 |
adjusting washer 0,75 |
|
| 20 |
02A311175C |
thrust washer 2nd/3rd gear 30,8X52X3,5 |
|
| 21 |
02J311325 |
needle bearing - 30,6X40X25,8 |
|
| 23 |
02A311269E |
synchronizer ring 3./4.GANG |
|
| 24 |
02A311301D |
synchronizing hub 3./4.gear |
|
| 25 |
088311311D |
spring |
|
| 26 |
02A311115E |
needle bearing - 29X40X24 |
|
| 28 |
02A311155A |
thrust washer 9,2X49X2,5 |
|
| 29 |
02A311375C |
roller sleeve 29X46X18,1 |
|
| 3 |
311405625F |
taper roller bearing 29X50,29X14,73 |
|
| 30 |
02A311361L |
gear 5-speed 36/43 |
|
| 31 |
02A311324C |
concave spring washer 24X52X2,65 |
|
| 32 |
02A311335D |
torx socket head combi-bolt M10X1X35,5 |
|
| 4 |
02D311206B |
support with taper roller bearing |
|
| 5 |
N 90364901 |
round seal 7X2-N |
|
| 6 |
N 01508311 |
hexagon nut, shouldered M8 |
|
| 7 |
02A311221 |
thrust washer 1.gear |
|
| 8 |
02J311251F |
change gear G >> 27 01 4 1.gear 34/9 |
|
| 9 |
02A311213C |
needle cage 38X43X25 |
|
