Оригинальный
номер |
Название |
Заказ |
| (1) |
045131501C |
exhaust recirculation valve lhd |
|
| (1) |
045131501 |
exhaust recirculation valve rhd |
|
| (24) |
045131055J |
vacuum hose lhd |
|
| (26) |
045131055L |
vacuum hose |
|
| (27) |
6X0131051C |
vacuum hoses rhd |
|
| (27) |
6X0131051D |
vacuum hoses for vehicle use in cold climates rhd |
|
| (27) |
6X0131051E |
vacuum hoses lhd |
|
| (27) |
6X0131051B |
vacuum hoses for vehicle use in cold climates F >> 6N-1D038 000* F >> 6N-1Y156 000* lhd |
|
| (27) |
6X0131051F |
vacuum hoses for vehicle use in cold climates F 6N-1D038 001>>* F 6N-1Y156 001>>* lhd |
|
| 10 |
028906283F |
solenoid change-over valve |
|
| 11 |
1J0906283A |
solenoid change-over valve |
|
| 12 |
046130405 |
retaining plate |
|
| 13 |
6X0906287E |
retainer |
|
| 14 |
046131887 |
grommet |
|
| 15 |
052129734 |
distance piece |
|
| 16 |
06A906300 |
stop buffer |
|
| 17 |
N 90106302 |
hexagon nut, shouldered M6 |
|
| 18 |
N 10196102 |
torx socket fillister hd. bolt EM6X18 |
|
| 19 |
N 90106302 |
hexagon nut, shouldered M6 |
|
| 2 |
N 90521601 |
round seal 55X3-N |
|
| 20 |
443957818C |
cable tie 7X273-8 |
|
| 21 |
N 10091101 |
pipe clip 7,5-9 |
|
| 24 |
045131055G |
vacuum hose rhd |
|
| 25 |
045131055E |
vacuum hose F >> 6N-1D038 000* F >> 6N-1Y156 000* rhd lhd |
|
| 28 |
6X0131051A |
vacuum hoses F >> 6N-1D038 000* F >> 6N-1Y156 000* rhd lhd |
|
| 3 |
N 10227803 |
allen key head bolt (combi) M6X20 |
|
| 4 |
045131521 |
connecting pipe |
|
| 5 |
069131547D |
gasket 32MM |
|
| 6 |
N 0903771 |
allen key head bolt (combi) M8X25Z3 |
|
| 7 |
038131547A |
gasket 22MM |
|
| 8 |
N 90200201 |
shouldered hex. nut, self-locking AM8 |
|
| 9 |
1H0906627 |
pressure converter |
|
