Оригинальный
номер |
Название |
Заказ |
| (14) |
3A0820721H |
refrigerant hose (refrigerant compressor > refrigerant condenser) |
|
| (14) |
3A0820721J |
refrigerant hose (refrigerant compressor > refrigerant condenser) |
|
| (15) |
3A0820739C |
refrigerant hose (refirgerant condensor > fluid container) |
|
| (16) |
3A1820741D |
refrigerant hose (fluid container > expansion valve) |
|
| (16) |
3A2820741B |
refrigerant hose (fluid container > expansion valve) rhd |
|
| (17) |
3A1820743D |
refrigerant hose (expansion valve > refrigerant compressor) lhd |
|
| (17) |
3A2820743C |
refrigerant hose (expansion valve > refrigerant compressor) rhd |
|
| (17) |
3A2820743D |
refrigerant hose (expansion valve > refrigerant compressor) rhd |
|
| (17) |
3A2820743E |
refrigerant hose (expansion valve > refrigerant compressor) rhd |
|
| (22) |
4A0820199 |
double cable tie for 4-speed automatic gearbox 7X213/140MM rhd |
|
| - |
357820745B |
protective tube 15,5X75MM 3A0 820 743 C |
|
| - |
357820745 |
protective tube 75MM |
|
| 1 |
171121276D |
rubber washer 3,5MM |
|
| 10 |
3A0820191 |
drier |
|
| 11 |
357820255A |
dual clip |
|
| 12 |
3A0820413A |
refrigerant condenser |
|
| 13 |
6N0820679C |
expansion valve R134A |
|
| 17 |
3A1820743E |
refrigerant hose (expansion valve > refrigerant compressor) lhd |
|
| 1819 |
3A1820743E |
refrigerant hose (expansion valve > refrigerant compressor) lhd |
|
| 2 |
034133335 |
cap 7MM |
|
| 20 |
1H0820749G |
round seal 20,35X1,78 |
|
| 21 |
3A0820751A |
grommet |
|
| 22 |
4A0820199 |
double cable tie 7X213/140MM rhd |
|
| 23 |
3A0820769E |
retainer refrigerant hose (expansion valve > refrigerant compressor) |
|
| 24 |
3A0820769D |
retainer refrigerant hose lock carrier |
|
| 25 |
3A1820769A |
retainer refrigerant hose lock carrier lhd |
|
| 26 |
3A1820769B |
retainer refrigerant hose lhd |
|
| 27 |
3A2820769 |
bracket for refrigerant hose rhd |
|
| 28 |
357820769E |
retainer refrigerant hose lhd |
|
| 29 |
357820775A |
dual clip |
|
| 3 |
191201248 |
bracket for fuel line rhd |
|
| 30 |
535820776 |
stop buffer |
|
| 31 |
3A0820787 |
bracket, lower part |
|
| 32 |
1H0955846 |
terminal 17,5 |
|
| 33 |
1H0971003A |
retainer |
|
| 34 |
N 01021527 |
hexagonal head bolt M6X15 |
|
| 35 |
N 01021710 |
hexagonal head bolt M6X20 |
|
| 36 |
N 0122265 |
spring washer B6X12X0,5 |
|
| 37 |
N 0139694 |
oval head panel screw B4,8X16 |
|
| 38 |
N 0154551 |
snap nut ST4,8X23,7X16 |
|
| 39 |
N 0206201 |
pipe clip D1-13X15 |
|
| 4 |
1J0820749B |
round seal 17X1,8 |
|
| 40 |
N 0206402 |
pipe clip D1-18X15 |
|
| 41 |
N 0206472 |
pipe clip B15X24GI |
|
| 42 |
N 0206901 |
pipe clip B20X28GI |
|
| 43 |
N 10092201 |
allen key head bolt (combi) M6X40 |
|
| 44 |
N 10258201 |
pipe clip AL12-22 |
|
| 45 |
N 90031701 |
snap nut M6X25,9X18 |
|
| 46 |
N 10227803 |
allen key head bolt (combi) M6X20 |
|
| 47 |
N 90215802 |
hexagonal nut M6SB |
|
| 48 |
N 90216201 |
hex. nut M6 |
|
| 49 |
N 90649601 |
cheese head bolt M6X14 |
|
| 4A |
8E0260749D |
round seal 14X1,8 |
|
| 5 |
8E0260749 |
round seal 10,8X1,82 |
|
| 50 |
N 90280901 |
hexagon head bolt (combi) M6X22 |
|
| 51 |
N 90908301 |
shouldered hex. nut, self-locking M8 |
|
| 52 |
N 90415102 |
allen key head bolt (combi) 10X32 |
|
| 53 |
N 90477301 |
washer B8,4X24X3 |
|
| 54 |
357972793B |
retaining panel rhd |
|
| 55 |
1H0959139B |
high-low pressure and fan switch |
|
| 56 |
357820795H |
valve |
|
| 57 |
357820809B |
protective cap |
|
| 58 |
357820795J |
valve |
|
| 59 |
357820809C |
protective cap |
|
| 6 |
8A0260749AK |
round seal 7,6X11,16 |
|
| 60 |
7D0820855 |
charge valve |
|
| 61 |
1H0820698 |
flange refrigerant hose (fluid container > expansion valve) |
|
| 7 |
811807577C |
insert nut |
|
| 8 |
321819017 |
gasket 680X8X10 |
|
| 9 |
321820061D |
gasket 1220X12X10 |
|
