Оригинальный
номер |
Название |
Заказ |
|
321201873 909 |
natural colours |
|
| (1) |
323201075 |
fuel tank |
|
| (18) |
321201253D |
pot F >> 32-D-300 000 |
|
| (2) |
321201129H |
fuel filler neck with restric- tion for leadfree fuel only |
|
| (2) |
321201129H |
fuel filler neck with restric- tion for leadfree fuel only for models with retro-fitted emission control system |
|
| (23A) |
323201308 |
shield for fuel tank for models with retro-fitted emission control system |
|
| (28) |
321201551K |
fuel tank cap for vehicles with central locking system F 32-E-096 736>> |
|
| (29) |
443201551AA |
cap, lockable for single key system with separate lock cylinder but without tumblers, springs and keys for fuel tank system a profile ah |
|
| (29) |
443201551S |
cap, lockable, not for one key locking system for fuel tank |
|
| - |
N 0202811 |
hose in coils of 5m order unit 5 7X3 |
|
| - |
N 90261401 |
pop-rivet A4,8X6,5X22 |
|
| - |
N 90099601 |
hose in coils of 5m order unit 5 5,5X3 |
|
| - |
N 0386021 |
nut,thread cutting 4X5,75 |
|
| - |
N 01166615 |
washer 6,4X18X1,6 |
|
| - |
431201511A |
fuel filter |
|
| - |
N 0202811 |
hose in coils of 5m order unit 5 7X3 |
|
| - |
321201254 |
plug F >> 32-D-300 000 |
|
| 1 |
321201075BC |
fuel tank |
|
| 11/12 |
171201153J |
breather hose with spring 1050MM |
|
| 13 |
N 90561801 |
pipe clip LC16-27 |
|
| 17 |
321201248A |
bracket for hose |
|
| 19 |
1H0201255 |
ring |
|
| 2 |
321201129G |
fuel filler neck |
|
| 20 |
N 0245281 |
pipe clip LC8-12 |
|
| 20A |
N 0245281 |
pipe clip LC8-12 |
|
| 20B |
N 10002201 |
clamp 13,8 |
|
| 21 |
321919133 |
seal 109 lhd |
|
| 22 |
321201375A |
union nut |
|
| 23B |
N 0123223 |
lock washer 10 |
|
| 23C |
N 0200251 |
plug A12X1 |
|
| 24 |
171201969 |
hexagon nut, shouldered 5 |
|
| 25 |
321201651C |
tensioning strap |
|
| 27 |
N 90908301 |
shouldered hex. nut, self-locking M8 |
|
| 3 |
N 0138905 |
hexagon head panel screw ST6,3X13-C |
|
| 30 |
811201557 |
gasket for vehicles with central locking system |
|
| 31 |
811201557A |
gasket |
|
| 32 |
161837219 |
main key profile hv quote key number for cut keys |
|
| 33 |
N 0241222 |
pipe clip 9X13 |
|
| 36 |
323201361 |
fuel pipe feed |
|
| 37 |
323201362 |
fuel pipe return |
|
| 38 |
321201739A |
flap for reservoir |
|
| 39 |
321201777 |
reservoir, lower part |
|
| 40 |
321201788 |
securing clip |
|
| 41 |
321201873 |
baffle vane |
|
| 5 |
321201139 |
support tube |
|
| 6A |
321201147 |
retainer |
|
| 6C |
N 0121053 |
lock washer A6,4 |
|
| 7 |
N 90123501 |
hose 48X4X90 |
|
| 8 |
N 0245044 |
pipe clip LC40-60 |
|
| 9 |
321201192 |
covering |
|
