Оригинальный
номер |
Название |
Заказ |
| (1) |
035903119C |
v-belt pulley for alternator: 17,19 |
|
| (1) |
035903119D |
v-belt pulley for alternator: 16B,18,20 |
|
| (11) |
068903171 |
fan wheel for alternator: 15,16,16A |
|
| (11) |
063903171 |
fan wheel for alternator: 16B,17,18,19, 20 |
|
| (11) |
068903171A |
fan wheel for alternator: 21 |
|
| (11A) |
035903187F |
intake cover for alternator: 21 |
|
| (12) |
055903253M |
angled bracket for alternator: 2 holes 16A,21 |
|
| (12A) |
035903253R |
angled bracket for alternator: 17,18,20 |
|
| (15) |
N 0197002 |
hexagon head bolt c/w shoulder for alternator: M8X30 16A |
|
| (4) |
N 0103533 |
hexagonal head bolt also use: M8X42 N 012 229 3 |
|
| - |
N 0122293 |
spring washer A8X15X0,5 |
|
| 1 |
068903119C |
v-belt pulley for alternator: 15,16,16A,21 |
|
| 10 |
052903147 |
bush |
|
| 10A |
035260689E |
support |
|
| 10B |
N 0102186 |
hexagonal head bolt also use: M6X25 N 011 524 23 |
|
| 11A |
035903193D |
intake cover for alternator: 15,16,16A |
|
| 11B |
035903193E |
intake cover for alternator: 17,18,19,20 |
|
| 11C |
N 01100517 |
hexagonal nut for alternator: M5 15,16,16A |
|
| 11D |
N 90529301 |
hexagonal head bolt for alternator: M6X10 17,18 |
|
| 12A |
035903253R |
angled bracket |
|
| 13 |
N 01037510 |
hexagonal head bolt M8X75 |
|
| 15 |
059903285 |
flat round head bolt for alternator: M8X25 15,16 |
|
| 15A |
035903285 |
flat round head bolt for alternator: M8X80 20,17,18 |
|
| 16 |
N 90908301 |
shouldered hex. nut, self-locking M8 |
|
| 17 |
069903137C |
v-belt 11,5X800MM |
|
| 18 |
N 0120442 |
spring ring A14 |
|
| 19 |
N 0111135 |
hexagonal nut M14X1,5 |
|
| 1A |
036903121 |
spring shackle for alternator: 15,16,16A |
|
| 2 |
035903141H |
retainer |
|
| 20 |
035903683 |
support |
|
| 21 |
N 01024016 |
hexagonal head bolt M8X20 |
|
| 22 |
N 01024416 |
hexagonal head bolt M8X30 |
|
| 23 |
N 01152520 |
washer A8,4X16X1,6 |
|
| 2A |
035903141J |
retainer |
|
| 2B |
N 90668201 |
bolt, with multi-spilne socket head M10X48 |
|
| 2C |
N 0122307 |
spring washer B10X21X1 |
|
| 3 |
N 90130001 |
hexagonal head bolt AM10X80 |
|
| 5 |
N 0122307 |
spring washer B10X21X1 |
|
| 6 |
N 01224110 |
spring washer B8X15X0,8 |
|
| 7 |
N 0103914 |
hexagonal head bolt M8X100 |
|
| 8 |
N 01152520 |
washer A8,4X16X1,6 |
|
| 9 |
N 0221464 |
hexagon nut, self-locking VM8 |
|
