Оригинальный
номер |
Название |
Заказ |
| (12) |
01E311351H |
change gear 4-speed |
|
| (24) |
01E311362A |
change gear 6th gear |
|
| (33) |
01E311361E |
change gear 5-speed |
|
| (35) |
N 90514004 |
securing ring 78X2,7 |
|
| (35) |
N 90514003 |
securing ring 78X2,65 |
|
| (35) |
N 90514002 |
securing ring 78X2,6 |
|
| (8) |
N 90294406 |
securing ring 37X2,05 |
|
| (8) |
N 90294405 |
securing ring 37X2,02 |
|
| (8) |
N 90294404 |
securing ring 37X1,99 |
|
| (8) |
N 90294403 |
securing ring 37X1,96 |
|
| (8) |
N 90294402 |
securing ring 37X1,93 |
|
| 1 |
01E311105H |
propshaft also use: Z=8+18 |
|
| 11 |
01E311115 |
needle cage 42X37X31,3 |
|
| 12 |
01E311351J |
change gear 4-speed |
|
| 13 |
01E311155 |
thrust washer |
|
| 14 |
N 90294405 |
securing ring 37X2,02 |
|
| 15 |
012311123 |
needle sleeve 29X41X22 |
|
| 16 |
N 10229801 |
securing ring B42X1,5 |
|
| 1A |
N 0133151 |
spring sleeve 5X10 |
|
| 2 |
01E311115 |
needle cage 42X37X31,3 |
|
| 20A |
01E311423 |
roller sleeve 43X62X17 |
|
| 20B |
01E311431 |
inner ring 30.1X43X28 |
|
| 21 |
N 0424551 |
securing ring A30 |
|
| 22 |
01E311413 |
thrust ring 6th gear |
|
| 23 |
01E311117 |
needle cage 30X35X32 |
|
| 24 |
01E311362B |
change gear 6th gear |
|
| 26 |
012311295F |
synchronizer ring also use: 3.gear |
|
| 28 |
01E311302 |
synchronizing hub with locking collar 5th/6th gear |
|
| 3 |
01E311285F |
change gear 3.gear |
|
| 3 |
01E311285E |
change gear 3.gear |
|
| 30A |
01E311122 |
inner ring 27X32X32,4 |
|
| 30B |
01E311118 |
needle cage 32X37X32 |
|
| 31 |
012311295F |
synchronizer ring also use: 3.gear |
|
| 33 |
01E311361B |
change gear 5-speed |
|
| 34 |
01E311449 |
baffle plate |
|
| 35 |
N 90514001 |
securing ring 78X2,55 |
|
| 36 |
01E311445 |
ball bearing 25X77,8X40,5 |
|
| 37 |
01E311125 |
roller sleeve 41X58X16 |
|
| 38 |
01E311308A |
union banto bolt with hex. socket hd. M17X1 |
|
| 40 |
01E311529A |
reverse gear Z=22 |
|
| 41 |
016311839D |
synchronizer ring reverse gear |
|
| 42 |
016311859C |
pressure spring |
|
| 43 |
016311519B |
reverse gear idler spindle |
|
| 44 |
016311853B |
retaining plate |
|
| 45 |
016311861C |
spring clasp |
|
| 46 |
088301291A |
bolt, hex. hd. with shoulder and shaft M8X11,5/11X4,5 |
|
| 5 |
012311295F |
synchronizer ring also use: 3.gear |
|
| 6 |
01E311301 |
synchronizing hub with locking collar 3./4.gear |
|
| 8 |
N 90294401 |
securing ring 37X1,9 |
|
| 9 |
012311295F |
synchronizer ring also use: 3.gear |
|
