Оригинальный
номер |
Название |
Заказ |
| (32) |
077903137L |
ribbed v-belt F 4C-N-000 001>>* 21,36X2480MM |
|
| (32) |
077903137G |
ribbed v-belt F >> 4C-M-020 000 21,36X2433MM |
|
| (35) |
077903417A |
retainer for vehicles with no air conditioning system F 4C-N-000 001>> |
|
| - |
811971848B |
retaining clip |
|
| - |
N 0206471 |
pipe clip D1-24X15 |
|
| - |
N 0209022 |
cable tie 6X246 |
|
| - |
N 90107604 |
washer F >> 4C-M-020 000 8,2X18X2 |
|
| - |
N 01152520 |
washer F 4C-N-000 001>> A8,4X16X1,6 |
|
| - |
N 0402681 |
hexagonal head bolt M6X14 |
|
| 1 |
077903119 |
pulley |
|
| 10 |
N 10181201 |
hexagonal head bolt M5X45 |
|
| 11 |
441971849B |
cable holder |
|
| 12 |
447971863A |
grommet 56X27/40X11 |
|
| 13 |
441903421A |
air guide |
|
| 14 |
N 0154481 |
snap nut ST4,2X16,3X11 |
|
| 15 |
N 01396626 |
oval head panel screw 4,2X13STC |
|
| 16 |
441903575 |
gasket |
|
| 17 |
077903125 |
bolt, torx socket head M8X65 |
|
| 18 |
077903409 |
retaining plate |
|
| 19 |
077903415 |
shaft |
|
| 2 |
N 0122385 |
spring washer B16X30X1,6 |
|
| 20 |
077903405 |
sleeve |
|
| 21 |
077903401 |
leg spring |
|
| 22 |
077903427B |
shock absorber |
|
| 23 |
N 0103594 |
hexagonal head bolt M8X38 |
|
| 23A |
N 01152520 |
washer A8,4X16X1,6 |
|
| 24 |
077903411 |
swing arm |
|
| 25 |
N 01023911 |
hexagonal head bolt M8X18 |
|
| 26 |
N 90179102 |
washer 8,2X18X3 |
|
| 27 |
077903341 |
relay roller |
|
| 28 |
N 0447041 |
allen key head bolt M8X28 |
|
| 29 |
N 0147135 |
allen key head bolt M8X35 |
|
| 3 |
N 0411817 |
hexagonal nut M16X1,5 |
|
| 30 |
077903343 |
protective cap |
|
| 31 |
077903403A |
relay roller for vehicles with no air conditioning system |
|
| 32 |
077903137D |
ribbed v-belt F >> 4C-M-020 000 21,36X2460MM |
|
| 33 |
N 0147172 |
allen key head bolt M8X40 |
|
| 34 |
078260817 |
centralising sleeve 11,15X6,5 |
|
| 35 |
077903417 |
retainer for vehicles with no air conditioning system F >> 4C-M-020 000 |
|
| 36 |
N 01034510 |
hexagonal head bolt also use: F 4C-N-000 001>> M8X45 |
|
| 36 |
N 0199035 |
allen key head bolt also use: F >> 4C-M-020 000 AM8X32 |
|
| 37 |
N 10036202 |
hexagon head bolt (combi) F >> 4C-M-020 000 M8X105 |
|
| 37 |
N 0103933 |
hexagonal head bolt F 4C-N-000 001>> M8X120 |
|
| 38 |
441903291 |
suppression condenser |
|
| 39 |
N 10102901 |
pipe clip D1-36X15 |
|
| 4 |
034903171 |
fan wheel BOSCH |
|
| 40 |
441903289 |
retainer |
|
| 41 |
N 90286703 |
hex. nut, self-locking with washer M6 |
|
| 42 |
N 0147035 |
allen key head bolt M6X18 |
|
| 5 |
N 90870401 |
hexagon socket head bolt with shoulder AM10X50-SW16 |
|
| 6 |
N 01034510 |
hexagonal head bolt M8X45 |
|
| 6A |
N 01152520 |
washer A8,4X16X1,6 |
|
| 7 |
077903199A |
connection piece |
|
| 8 |
077903193 |
protective cap alternator |
|
| 9 |
N 0102076 |
hexagonal head bolt M5X12 |
|
| 9A |
N 0122224 |
spring washer A5X10X0,5 |
|
