Оригинальный
номер |
Название |
Заказ |
| (1) b |
4B0407272BD |
drive shaft with constant velocity joints right |
|
| (1) b# |
4B0407451JX |
drive shaft with constant velocity joints left |
|
| (1) b# |
4B0407452JX |
drive shaft with constant velocity joints right |
|
| (2) |
4A0407643A |
shouldered bolt M16X1,5X77 |
|
| 1 b |
4B0407271BD |
drive shaft with constant velocity joints left |
|
| 10 |
N 90739901 |
hose clip 31X10X0,8 |
|
| 15 |
N 0123741 |
securing ring 28X1,5 |
|
| 17 * |
8D0407309A |
sealing washer 94MM |
|
| 2 * |
4B0407643A |
shouldered bolt M16X1,5X72 |
|
| 20 |
4D0407720 |
shield right |
|
| 22 |
N 10413501 |
allen key head bolt (combi) M8X28 |
|
| 23 |
G 052133A3 |
high temperature grease 120G |
|
| 24 |
N 90668201 |
bolt, with multi-spilne socket head M10X48 |
|
| 25 |
443407357 |
spacer plate front |
|
| 26 |
8E0498099 |
wheel shaft, outer with joint, rotor and assembly parts outer |
|
| 28 |
4Z7598103 |
constant velocity joint with boot, attachment parts and grease inner |
|
| 3 |
N 90772401 |
terminal 92,5X10X1 |
|
| 30 b |
443498201B |
joint protective boot with assembly items and grease inner |
|
| 32 b |
8E0498203 |
joint protective boot with assembly items and grease outer |
|
| 5 |
N 90890001 |
securing ring 27X1.8 |
|
