Оригинальный
номер |
Название |
Заказ |
| (1) b |
4B0407272C |
drive shaft with constant velocity joints right |
|
| (1) b |
4B0407271BA |
drive shaft with constant velocity joints left |
|
| (1) b |
4B0407272BA |
drive shaft with constant velocity joints right |
|
| (1) b# |
4B0407451HX |
drive shaft with constant velocity joints left |
|
| (1) b# |
4B0407452HX |
drive shaft with constant velocity joints right |
|
| (12) |
N 90442701 |
hose clip 107X9X0,6 |
|
| (25) |
N 10413501 |
allen key head bolt (combi) M8X28 |
|
| (28) |
4D0498099 |
wheel shaft, outer with joint, rotor and assembly parts outer |
|
| (28) # |
8D0498099DX |
wheel shaft, outer with joint, rotor and assembly parts outer |
|
| (3) b |
4B0407418A |
drive shaft with constant velocity joint inner right |
|
| (36) |
4A0407643A |
shouldered bolt M16X1,5X77 |
|
| 1 b |
4B0407271C |
drive shaft with constant velocity joints left |
|
| 10 |
N 90818201 |
securing ring A29X2 |
|
| 12 |
N 90928201 |
clamp 108 |
|
| 14 |
441407293 |
terminal 33 |
|
| 16 |
N 90660101 |
hose clip 93,5 |
|
| 18 |
N 0124121 |
securing ring 25X1,2 |
|
| 22 |
8D0407719 |
shield left front |
|
| 23 |
4D0407720 |
shield right front |
|
| 25 |
N 90415403 |
allen key head bolt (combi) M8X22-Z1 |
|
| 26 |
G 000605 |
high temperature grease 140G |
|
| 28 |
8D0498099D |
wheel shaft, outer with joint, rotor and assembly parts outer |
|
| 3 b |
4B0407417A |
drive shaft with constant velocity joint inner left |
|
| 31 b |
4B0498201 |
joint protective boot with assembly items and grease inner |
|
| 34 b |
441498203A |
joint protective boot with assembly items and grease outer |
|
| 35 |
N 10207701 |
clamp 34,6X7X0,6 |
|
| 36 |
4B0407643A |
shouldered bolt M16X1,5X72 |
|
| 4 |
N 90441102 |
bolt, with multi-spilne socket head M10X20 |
|
| 7 * |
441407297 |
securing ring outer |
|
| 8 |
441407295 |
thrust ring |
|
| 9 * |
441407287 |
concave spring washer |
|
