Оригинальный
номер |
Название |
Заказ |
|
4B2713141J KQK |
jive (grey beige) -WJ |
|
|
4B1713141J KQF |
satin black -WA,WE,WK,WL, |
|
|
4B1713141J KQG |
swing (dark grey) -WC,WF |
|
|
4B1713141J KQH |
blues -WB,WG,WT,WU |
|
|
4B1713141J KQK |
jive (grey beige) -WJ |
|
|
4D2713141C KQF |
satin black -WA,WE,WK,WL |
|
|
4D2713141C KQH |
blues -WB,WG |
|
|
4D2713141C KQJ |
jazz -WD,WH |
|
|
4D2713141C KQK |
jive (grey beige) -WJ |
|
|
4B2713141J KQF |
satin black -WA,WE,WK,WL, |
|
|
4B2713141J KQG |
swing (dark grey) -WC,WF |
|
|
4B2713141J KQH |
blues -WB,WG,WT,WU |
|
|
4B2713141J KQJ |
jazz -WD,WH,WM |
|
|
4D1713141C KQK |
jive (grey beige) -WJ |
|
|
4D1713141C KQJ |
jazz -WD,WH |
|
|
4D1713141C KQH |
blues -WB,WG |
|
|
4B1713141J KQJ |
jazz -WD,WH,WM |
|
|
4D1713141C KQG |
swing (dark grey) -WC,WF |
|
| (1) |
4D0713109C |
ball housing - gearshift lever F 4D-1-000 001>> 4D-1-020 000 |
|
| (1) |
4D0713109D |
ball housing - gearshift lever F 4D-2-000 001>> |
|
| (13) b |
4D2713575A |
wire cable rhd |
|
| (2) |
4D0713111F |
cover for selector mechanism F 4D-2-000 001>> |
|
| (21) |
4D0927151D |
tiptronic-unit F 4D-1-000 001>> |
|
| (24) |
4D0713195E |
selector lever F 4D-1-000 001>> |
|
| (3) |
4D0713243E |
bulb holder with leads F 4D-2-000 001>> |
|
| (4) |
4D0713191H |
insert F 4D-2-000 001>> |
|
| (42) |
4D0713177B |
locking piece F 4D-1-000 001>> |
|
| (49) |
4D0713217B |
retaining panel right |
|
| (52) |
4D0927353B |
electro magnet F 4D-1-000 001>> |
|
| (7) |
4B2713141J |
gearstick grip (leather) rhd |
|
| (7) |
4D2713141C |
gearstick grip (leather) rhd |
|
| (7) |
4B1713141J |
gearstick grip (leather) lhd |
|
| - |
G 052142A2 |
poly lubricant 400G |
|
| 1 |
4D0713109B |
ball housing - gearshift lever F >> 4D-Y-020 000 |
|
| 10 |
4D0713247A |
bulb holder with leads |
|
| 11 |
4D0713187A |
cover strips |
|
| 12 |
4D0713189B |
guide |
|
| 13 b |
4D1713575A |
wire cable lhd |
|
| 15 |
N 01152423 |
washer A6,4X12,5X1,6 |
|
| 16 |
N 01021527 |
hexagonal head bolt M6X15 |
|
| 17 |
803959849 |
retainer |
|
| 18 |
N 01152423 |
washer A6,4X12,5X1,6 |
|
| 19 |
N 01021527 |
hexagonal head bolt M6X15 |
|
| 2 |
4D0713111E |
cover for selector mechanism F >> 4D-1-020 000 |
|
| 20 |
N 90368203 |
snap nut M5X21X15 |
|
| 21 |
4D0927151C |
tiptronic-unit F >> 4D-Y-020 000 |
|
| 22 |
N 01152423 |
washer A6,4X12,5X1,6 |
|
| 23 |
N 0147018 |
allen key head bolt M6X12MK |
|
| 24 |
4D0713195C |
selector lever F >> 4D-Y-020 000* |
|
| 25 |
4D0713251A |
pull rod |
|
| 26 |
4D0713149 |
pressure spring |
|
| 27 |
4D0713229B |
pin |
|
| 28 |
4D0713274A |
securing clip |
|
| 29 |
8D0713816 |
securing clip |
|
| 3 |
4D0713243D |
bulb holder with leads F >> 4D-1-020 000 |
|
| 30 b |
4D0713265K |
cable for shift mechanism rear |
|
| 31 b |
4D0713266B |
cable for shift mechanism front |
|
| 33 |
8D0713281C |
abutment |
|
| 34-35 |
N 10049303 |
hexagon head bolt (combi) M8X20 |
|
| 36 |
4D0713383E |
shield |
|
| 37 |
N 01152423 |
washer A6,4X12,5X1,6 |
|
| 38 |
N 01021527 |
hexagonal head bolt M6X15 |
|
| 39 |
4D0713835 |
locking lever |
|
| 4 |
4D0713191G |
insert F >> 4D-1-020 000 |
|
| 40 |
4D0713274B |
securing clip |
|
| 41 |
4D0713179 |
lever |
|
| 42 |
4D0713177A |
locking piece F >> 4D-Y-020 000 |
|
| 43 |
4D0713135A |
locking segment |
|
| 44 |
4D0713135 |
locking segment |
|
| 46 |
4D0713274C |
securing clip |
|
| 47 |
4D0713193A |
packing plate |
|
| 48 |
N 90440702 |
hexagonal head bolt M6X15 |
|
| 49 |
4D0713217A |
retaining panel left |
|
| 5 |
4D0711172A |
stop for gearshift rod, rear F 4D-2-000 001>> |
|
| 50 |
N 01152423 |
washer A6,4X12,5X1,6 |
|
| 51 |
N 0147018 |
allen key head bolt M6X12MK |
|
| 52 |
8D0927353 |
electro magnet F >> 4D-Y-020 000 |
|
| 53 |
4D0713229A |
pin |
|
| 54 |
8D0713274 |
lock plate |
|
| 55 |
4D0713274E |
securing clip |
|
| 56 |
4D0713389 |
abutment |
|
| 57-58 |
N 10049303 |
hexagon head bolt (combi) M8X20 |
|
| 59 |
4D0713274D |
securing clip |
|
| 6 |
4D0711171 |
stop buffer F 4D-2-000 001>> |
|
| 7 |
4D1713141C |
gearstick grip (leather) lhd |
|
| 8 |
N 90040901 |
seal 14X1,78N |
|
| 9 |
4D0713170A |
sleeve |
|
