Оригинальный
номер |
Название |
Заказ |
| (1) |
026103101N |
cylinder block with pistons |
|
| (1) |
048103101B |
cylinder block with pistons |
|
| (1) |
053100103DX |
short engine 103KW |
|
| (11) |
053905261B |
seal |
|
| (12) |
N 0162011 |
cup rivet AK4,8X14 |
|
| (22) |
048103771 |
gasket |
|
| (30) |
022103139 |
dowel sleeve F 4A-N-000 001>> 16X13,5 |
|
| (45) |
06B103551 |
intermediate plate |
|
| - |
N 0122265 |
spring washer B6X12X0,5 |
|
| - |
044103609D |
gasket |
|
| - |
N 90412101 |
hexagon head bolt (combi) M6X25-S4 |
|
| 1 |
048103101D |
cylinder block with pistons |
|
| 11 |
056103541 |
bush |
|
| 12 |
056103117 |
plug 6,4MM |
|
| 13 |
N 01024016 |
hexagonal head bolt M8X20 |
|
| 14 |
036103113A |
locking cover 36,6 |
|
| 14A |
N 0119077 |
locking cover A14 |
|
| 15 |
026103139 |
parallel dowel pin 6M6X20 |
|
| 16 |
051103152 |
sealing flange |
|
| 17 |
026103161B |
gasket |
|
| 18 |
N 01021612 |
hexagonal head bolt also use: M6X18 |
|
| 19 |
053103155E |
pressure relief valve |
|
| 2 |
N 10263801 |
hexagonal head bolt M10X65 |
|
| 20 |
053103157A |
oil spray jet |
|
| 21 |
048103772 |
breather assy. |
|
| 23 |
N 90467301 |
round seal 34,2X3 |
|
| 24 |
N 90221803 |
allen key head bolt (combi) M8X20 |
|
| 25 |
068103171F |
sealing flange rear |
|
| 26 |
026103181B |
gasket |
|
| 27 |
N 0432072 |
parallel dowel pin 8H8X14 |
|
| 3 |
. |
discontinued / replacement: 068 103 171 F |
|
| 30 |
014301153 |
dowel sleeve F >> 4A-M-100 000 16X12,8 |
|
| 33 |
048103601 |
oil sump also use: |
|
| 33A |
053103623 |
baffle |
|
| 34 |
044103609D |
gasket also use: |
|
| 35 |
N 0138492 |
seal A14X20 |
|
| 36 |
N 90288901 |
sealing plug M14X1,5X16 |
|
| 37 |
N 90008401 |
hexagon head bolt c/w shoulder M6X14 |
|
| 38 |
049103634 |
tube for oil dipstick |
|
| 39 |
053103663 |
guide funnel |
|
| 4 |
068103085E |
oil seal 47X10 |
|
| 5 |
036103113A |
locking cover 36,6 |
|
| 6 |
N 01024222 |
hexagonal head bolt M8X25 |
|
| 7 |
N 01224110 |
spring washer B8X15X0,8 |
|
| 8 |
028905256 |
retainer |
|
