Оригинальный
номер |
Название |
Заказ |
| (22) |
049133777C |
plug for co adjusting screw |
|
| (22) |
049133777B |
plug for co adjusting screw |
|
| (32) |
035133403G |
warm-up valve |
|
| (32) |
034133403 |
warm-up valve |
|
| (32) |
035133403D |
warm-up valve F >> 44-E-024 680* |
|
| (39) |
035133471N |
air flow meter |
|
| (39) |
035133471T |
air flow meter on-board computer |
|
| (4) |
034133063E |
throttle valve adapter |
|
| (40) |
035133481L |
fuel metering valve |
|
| (4A) |
035133093C |
switch with loom idling switch |
|
| (4A) |
035133093D |
full throttle switch |
|
| (51A) |
034133837AR |
air cleaner |
|
| (55A) |
035133853D |
air hose 60,4/55,2X300 |
|
| (59) |
431129669 |
grommet |
|
| (8) |
035133201AN |
intake connection |
|
| - |
N 0116653 |
washer 5,3X15X1,6 |
|
| - |
034133969C |
retainer |
|
| - |
035133521G |
air hose |
|
| - |
056129777 |
cap 4MM |
|
| - |
068121324 |
cap 14MM |
|
| - |
N 0122265 |
spring washer B6X12X0,5 |
|
| - |
N 0122293 |
spring washer A8X15X0,5 |
|
| - |
035133382T |
t-piece |
|
| - |
035133095C |
retainer |
|
| 1 |
027129627E |
warm air hose 50,8X550MM |
|
| 10 |
N 90144201 |
allen key head bolt (combi) M8X65Z1 |
|
| 12 |
059103113 |
locking cover 36,6 |
|
| 17 |
N 01021710 |
hexagonal head bolt also use: M6X20 |
|
| 18 |
N 0122265 |
spring washer B6X12X0,5 |
|
| 19 |
035133357M |
elbow use if required: |
|
| 2 |
N 0245044 |
pipe clip LC40-60 |
|
| 20 |
N 0245212 |
pipe clip AL120-140 |
|
| 21 |
N 0245183 |
pipe clip AL70-90 |
|
| 22 |
049133777A |
plug for co adjusting screw |
|
| 24 |
049133379A |
gasket |
|
| 27 |
034129717M |
gasket alternatively: |
|
| 28 |
N 01023820 |
hexagonal head bolt M8X15 |
|
| 29 |
N 01224110 |
spring washer B8X15X0,8 |
|
| 3 |
867129797 |
sealing clip |
|
| 30 |
N 90085001 |
hexagon nut, self-locking M8 |
|
| 31 |
055129723A |
support |
|
| 32 |
035133403E |
warm-up valve |
|
| 33 |
443972525 |
grommet flat connector housing |
|
| 33A |
063133415 |
protective cap |
|
| 34 |
N 0447033 |
allen key head bolt M6X45 |
|
| 35 |
049133432 |
adjusting screw |
|
| 38 |
049133777B |
plug for co adjusting screw |
|
| 39 |
035133471L |
air flow meter |
|
| 39B |
035133472B |
potentiometer on-board computer |
|
| 39C |
035133476 |
round seal on-board computer 43,2X2 |
|
| 40 |
035133481JX |
fuel metering valve |
|
| 41 |
035133483C |
cheese head bolt |
|
| 42 |
034133476 |
round seal 29,5X1,5 |
|
| 5 |
037133073A |
gasket |
|
| 51 |
034133837AR |
air cleaner rhd |
|
| 51 |
034133837AR |
air cleaner |
|
| 54 |
021129620 |
air cleaner element |
|
| 55 |
035133849 |
air cleaner housing |
|
| 55A |
035133853C |
air hose 60,4/55,2X435 |
|
| 55B |
035133857 |
bracket for hose |
|
| 55C |
N 0154581 |
snap nut B4,8X19X16 |
|
| 56 |
N 0139681 |
oval head panel screw also use: ST4,8X13-C |
|
| 56A |
035133873C |
intake manifold |
|
| 56A |
035133873C |
intake manifold rhd |
|
| 57 |
035133865B |
intake pipe with control box lhd |
|
| 57A |
034133861 |
sleeve |
|
| 59 |
055129669 |
rubber mounting 17/11,8 |
|
| 6 |
N 0147172 |
allen key head bolt also use: M8X40 |
|
| 60 |
N 01167016 |
washer B8,4X24X2 |
|
| 61 |
N 01224110 |
spring washer B8X15X0,8 |
|
| 62 |
N 01024222 |
hexagonal head bolt M8X25 |
|
| 8 |
035133201AM |
intake connection |
|
