Оригинальный
номер |
Название |
Заказ |
|
6113225 |
Hose - Air Cleaner Intake from 15/5/1985 | Fiesta 84/89/94 XR2 1.6L CVH 2V |
|
| 1 |
6136474 |
Cleaner Assy - Air from 15/5/1985 | Fiesta XR2 1.6L CVH 2V Carburett |
|
| 10 |
6049935 |
Washer - Rubber | |
|
| 11 |
6088529 |
Intake - Air Cleaner Preheat from 15/8/1980 to 15/3/1983 | |
|
| 11 |
6136475 |
Intake - Air Cleaner Preheat from 15/10/1984 | (+)"CH/S" |
|
| 11 |
6118689 |
Intake - Air Cleaner Preheat from 15/10/1984 | (-)"CH/S" from 15/3/1983 t |
|
| 12 |
1494349 |
Bolt - Hex.Head | GB |
|
| 12 |
0240909 |
Bolt - Hex.Head | D/E |
|
| 13 |
1444685 |
Washer | |
|
| 14 |
6101300 |
Hose - Pre-Heater from 15/8/1980 to 15/3/1983 | |
|
| 14 |
6165787 |
Hose - Pre-Heater from 15/3/1983 | |
|
| 15 |
1629378 |
Hose - Pre-Heater to 15/4/1984 | from 15/4/1984 to 15/1/1986 | |
|
| 16 |
6085507 |
Adaptor to 15/4/1984 | |
|
| 17 |
1475466 |
Screw | |
|
| 17 |
6095084 |
Screw | |
|
| 18 |
6163351 |
Washer | |
|
| 19 |
1579522 |
Nut - Spring | |
|
| 2 |
6064881 |
Element Assy - Air Cleaner | |
|
| 20 |
5009884 |
Clamp - Hose | |
|
| 21 |
1562575 |
Tube - Vacuum | | |
|
| 23 |
1480662 |
Screw | |
|
| 25 |
6165599 |
Hose - Air Cleaner Intake from 15/1/1986 | |
|
| 26 |
6077809 |
Screw | |
|
| 27 |
6099697 |
Bumper from 15/10/1984 | from 15/8/1982 to 15/10/19 |
|
| 29 |
6137828 |
Hose - Connecting | CVH 1.6H |
|
| 3 |
6110820 |
Sensor Assy from 15/10/1984 | from 15/8/1982 to 15/10/19 |
|
| 3 |
6103455 |
Sensor Assy to 15/10/1984 | Manual Transmission |
|
| 30 |
5013960 |
Hose - Connecting | |
|
| 31 |
0241209 |
Clamp - Hose | |
|
| 4 |
6036431 |
Gasket to 15/10/1984 | Manual Transmission from 15/ |
|
| 5 |
1562900 |
Retainer to 15/10/1984 | Manual Transmission |
|
| 5 |
6122295 |
Retainer from 15/10/1984 | from 15/8/1982 to 15/10/19 |
|
| 6 |
6083115 |
Grommet | |
|
| 7 |
6141136 |
Filter Assy - Crankcase Ventilation from 15/8/1983 to 15/11/1984 | Manual Transmissio |
|
| 7 |
6141135 |
Filter Assy - Crankcase Ventilation to 15/8/1983 | from 15/11/1984 | Fiesta |
|
| 8 |
6022315 |
Screw | (-)"TR" |
|
| 9 |
0227076 |
Washer - Flat | |
|
