Оригинальный
номер |
Название |
Заказ |
| 1 |
4004092 |
Back Assy - Seat from 15/1/1999 to 15/6/2000 | (-)"TH" |
|
| 1 |
4004094 |
Back Assy - Seat from 15/1/1999 to 15/8/2002 | (-)"Aus/T" |
|
| 1 |
4169750 |
Back Assy - Seat from 15/6/2000 to 15/8/2002 | (-)"TH" |
|
| 10 |
4004466 |
Valance - Seat Cushion from 15/6/1998 | |
|
| 10 |
4004465 |
Valance - Seat Cushion from 15/6/1998 | |
|
| 11 |
3807439 |
Cover - Seat Back Hinge from 15/6/1998 | |
|
| 11 |
3805768 |
Cover - Seat Back Hinge from 15/6/1998 | |
|
| 12 |
4050117 |
Knob - Seat Back Latch Handle from 15/6/1998 | |
|
| 13 |
4042839 |
Adjuster And Track Assy - Seat from 15/2/1999 | LHD |
|
| 13 |
4042845 |
Adjuster And Track Assy - Seat from 15/2/1999 | LHD |
|
| 13 |
4035427 |
Adjuster And Track Assy - Seat from 15/6/1998 | RHD |
|
| 13 |
4035428 |
Adjuster And Track Assy - Seat from 15/6/1998 | RHD |
|
| 14 |
4006193 |
Cable - Seat Track Adjustment from 15/6/1998 | |
|
| 15 |
4005952 |
Screw - Self-Tapping from 15/6/1998 | |
|
| 16 |
4005951 |
Screw - Self-Tapping from 15/6/1998 | |
|
| 17 |
4004706 |
Bolt from 15/6/1998 | |
|
| 18 |
4004703 |
Bolt from 15/6/1998 | |
|
| 19 |
3802203 |
Bolt from 15/6/1998 to 15/1/2000 | |
|
| 2 |
4004063 |
Cushion Assy - Seat from 15/11/1998 to 15/6/2000 | (-)"TH" |
|
| 2 |
1332887 |
Cushion Assy - Seat from 15/10/2001 to 15/8/2002 | (-)"Aus/T" |
|
| 2 |
3803416 |
Cushion Assy - Seat from 15/1/1999 to 15/8/2002 | (-)"Aus/T" |
|
| 2 |
4132739 |
Cushion Assy - Seat from 15/6/2000 to 15/8/2002 | (+)"GEN" (-)"TH" |
|
| 20 |
3802189 |
Bolt from 15/6/1998 to 15/12/1999 | |
|
| 20 |
4107048 |
Bolt from 15/12/1999 | |
|
| 21 |
4005954 |
Clip from 15/6/1998 | |
|
| 22 |
3803532 |
Bush - Hinge from 15/6/1998 | |
|
| 3 |
3807442 |
Cover Assy - Front Seat Cushion from 15/1/1999 to 15/8/2002 | (-)"Aus/T" |
|
| 3 |
4004129 |
Cover Assy - Front Seat Cushion from 15/11/1998 to 15/6/2000 | (-)"TH" |
|
| 3 |
4132745 |
Cover Assy - Front Seat Cushion from 15/6/2000 to 15/8/2002 | (-)"TH" |
|
| 4 |
4004154 |
Cover Assy - Seat Back from 15/11/1998 to 15/6/2000 | (-)"TH" |
|
| 4 |
4170052 |
Cover Assy - Seat Back from 15/6/2000 to 15/8/2002 | (-)"TH" |
|
| 5 |
3803517 |
Headrest - Cover And Pad from 15/1/1999 | (-)"Aus/T" |
|
| 5 |
4005993 |
Headrest - Cover And Pad from 15/11/1998 to 15/6/2001 | (-)"TH" |
|
| 5 |
4355636 |
Headrest - Cover And Pad from 15/6/2001 | (-)"TH" |
|
| 6 |
4355634 |
Cover - Headrest - Roll Type from 15/6/2001 | (-)"TH" |
|
| 6 |
4355638 |
Cover - Headrest - Roll Type from 15/6/2001 | (-)"Aus/T" |
|
| 6 |
4005990 |
Cover - Headrest - Roll Type from 15/11/1998 to 15/6/2001 | (-)"TH" |
|
| 6 |
3803501 |
Cover - Headrest - Roll Type from 15/1/1999 to 15/6/2001 | (-)"Aus/T" |
|
| 7 |
4006178 |
Sleeve - Headrest Guide from 15/6/1998 | |
|
| 8 |
4006177 |
Sleeve - Headrest Guide from 15/6/1998 | |
|
| 9 |
4004600 |
Stem And Buckle Assy from 15/2/1999 | Single Cab (2 Door) LHD (+)"IL" |
|
| 9 |
4004459 |
Stem And Buckle Assy from 15/1/1999 | (-)"IL" from 15/2/1999 | S |
|
