Оригинальный
номер |
Название |
Заказ |
| (10) |
7H0809392A |
reinforcem. for striker plate right |
|
| (12) |
7H3809341 |
end plate side member for models with wheelbase: left rear 3400 MM |
|
| (12) |
7H1809342 |
end plate side member right rear |
|
| (12) |
7H3809342 |
end plate side member for models with wheelbase: right rear 3400 MM |
|
| (14) |
7H0809631C |
reinforcement for pillar c (sliding door, left) F 7H-4-120 001>>* left inner |
|
| (14) |
7H0809631A |
reinforcement for pillar c (sliding door, left) F >> 7H-4-120 000* left inner |
|
| (16) |
7H0810061 |
support plate (sliding door, left) left lower |
|
| (18) |
7H0809065 |
support plate (sliding door, left) left upper |
|
| (25) |
7H0843549D |
channel (sliding door, left) left lower |
|
| (40) |
7H0810972 |
wheel housing-plastic material right rear |
|
| (5) |
7H3809159AA |
outer panel for side panel for vehicles with sliding door cut-out for models with wheelbase: left 3400 MM |
|
| (5) |
7H3809159T |
outer panel for side panel for vehicles with sliding door cut-out for models with wheelbase: left 3400 MM |
|
| (5) |
7H1809159L |
outer panel for side panel left |
|
| (5) |
7H3809159Q |
outer panel for side panel for models with wheelbase: left 3400 MM |
|
| (5) |
7H1809159Q |
outer panel for side panel left |
|
| (5) |
7H3809159M |
outer panel for side panel for models with wheelbase: left 3400 MM |
|
| (5) |
7H1809159T |
outer panel for side panel for vehicles with sliding door cut-out left |
|
| (5) |
7H1809159AA |
outer panel for side panel for vehicles with sliding door cut-out left |
|
| (5) |
7H3809159L |
outer panel for side panel for models with wheelbase: left 3400 MM |
|
| (6) |
7H1809160L |
outer panel for side panel right |
|
| (6) |
7H1809160Q |
outer panel for side panel right |
|
| (6) |
7H3809160T |
outer panel for side panel for vehicles with sliding door cut-out for models with wheelbase: right 3400 MM |
|
| (6) |
7H3809160Q |
outer panel for side panel for models with wheelbase: right 3400 MM |
|
| (6) |
7H3809160M |
outer panel for side panel for models with wheelbase: right 3400 MM |
|
| (6) |
7H3809160L |
outer panel for side panel for models with wheelbase: right 3400 MM |
|
| (6) |
7H3809160AA |
outer panel for side panel for vehicles with sliding door cut-out for models with wheelbase: right 3400 MM |
|
| (6) |
7H1809160T |
outer panel for side panel for vehicles with sliding door cut-out right |
|
| (6) |
7H1809160M |
outer panel for side panel right |
|
| (7) |
7H1809843B |
sub-part - side panel left rear outer |
|
| (7) |
7H1809844C |
sub-part - side panel right rear outer |
|
| (7) |
7H1809844B |
sub-part - side panel right rear outer |
|
| (7) |
7H1809844A |
sub-part - side panel right rear outer |
|
| (7) |
7H1809843C |
sub-part - side panel left rear outer |
|
| (8) |
7H1809843D |
sub-part - side panel for vehicles with sliding door cut-out left rear lower |
|
| (8) |
7H1809843A |
sub-part - side panel for vehicles with sliding door cut-out left rear lower |
|
| (8) |
7H1809844D |
sub-part - side panel for vehicles with sliding door cut-out right rear lower |
|
| - |
7H0809932 |
leaf spring flap for fuel filler |
|
| - |
7H0809879 |
cover cap for vehicles with sliding door |
|
| 1 |
7H0810075 |
side panel frame left outer |
|
| 10 |
7H0809391A |
reinforcem. for striker plate left |
|
| 12 |
7H1809341 |
end plate side member left rear |
|
| 14 |
7H0809632A |
reinforcement for pillar c (sliding door, right) F >> 7H-4-120 000* right inner |
|
| 14 |
7H0809632C |
reinforcement for pillar c (sliding door, right) F 7H-4-120 001>>* right inner |
|
| 16 |
7H0810062 |
support plate (sliding door, right) right lower |
|
| 18 |
7H0809066 |
support plate (sliding door, right) right upper |
|
| 2 |
7H0810076 |
side panel frame right outer |
|
| 25 |
7H0843550C |
channel (sliding door, right) right lower |
|
| 30 |
7H0809905 |
flap for fuel filler |
|
| 32 |
N 90960701 |
torx socket, half-round head (combi)bolt M5X16 |
|
| 35 |
N 90814601 |
rivetted cap nut M5/0,5-3-E |
|
| 36 |
7H0809948 |
stop cap flap for fuel filler |
|
| 40 |
7H0810971 |
wheel housing-plastic material left rear |
|
| 42 |
N 10516801 |
expanding nut F5 |
|
| 45 |
N 90897401 |
torx socket head panel screw 5X16-Q |
|
| 47 |
N 90323501 |
clips 12,5X10X1,5/2 |
|
| 49 |
N 90780901 |
torx socket fillister hd. bolt M6X16 |
|
| 5 |
7H1809159M |
outer panel for side panel left |
|
| 6 |
7H1809160AA |
outer panel for side panel for vehicles with sliding door cut-out right |
|
| 7 |
7H1809843 |
sub-part - side panel left rear outer |
|
| 8 |
7H1809844 |
sub-part - side panel for vehicles with sliding door cut-out right rear lower |
|
