Оригинальный
номер |
Название |
Заказ |
| (1) |
036129711DN |
intake connection |
|
| (1) |
030129711BP |
intake connection |
|
| (1) |
030129711BN |
intake connection |
|
| (11) |
036133062L |
throttle valve control unit also use: 035 133 335 N 100 834 01 |
|
| (11) |
030133062C |
throttle valve control unit |
|
| (12) |
N 10080202 |
allen key head bolt (combi) M6X50-Z1 |
|
| (12) |
N 10099301 |
allen key head bolt (combi) M6X65 |
|
| (13) |
030131503F |
exhaust recirculation valve |
|
| (14) |
030131547B |
gasket |
|
| (15) |
N 90500601 |
hexagon socket head bolt with collar M6X22 |
|
| (15) |
N 0147495 |
allen key head bolt M6X40 |
|
| (18) |
030131550 |
gasket |
|
| (19) |
N 0147404 |
allen key head bolt M6X16 |
|
| (20) |
030131521M |
connecting pipe |
|
| (20) |
036131521R |
connecting pipe |
|
| (20A) |
036131521AD |
connecting pipe |
|
| (21) |
036131550 |
seal |
|
| (22) |
N 10528501 |
hexagon head panel screw 5,5X25-H |
|
| (3) |
030133073D |
seal 52X2,5X5,35 |
|
| (32) |
036133518AH |
connecting hose |
|
| (32) |
030133518P |
connecting hose |
|
| (36) |
036131550H |
gasket |
|
| (37) |
036131547F |
gasket |
|
| (38) |
036131547F |
gasket |
|
| (39) |
030133778C |
vacuum hose |
|
| (39) |
036133773D |
connecting hose |
|
| (4) |
030198717 |
set of seals |
|
| (41) |
N 0102935 |
hexagonal head bolt M8X16 |
|
| (6) |
06B906051 |
thrust sensor |
|
| (9) |
N 90434702 |
oval head panel screw E4,8X16 |
|
| - |
N 0201391 |
tube in coils of 5m order unit 5 4X1 |
|
| - |
N 10083401 |
clamp 14,8X6X1 |
|
| - |
035133335 |
cap 8 |
|
| - |
N 0203535 |
hose in coils of 5m order unit 5 3,5X2 |
|
| 1 |
036129711BL |
intake connection |
|
| 10 |
N 90635401 |
allen key head bolt M8X38Z1 |
|
| 11 |
036133064D |
throttle valve control unit |
|
| 12 |
N 10190701 |
allen key head bolt (combi) M6X35-S4-N |
|
| 13 |
036131503D |
exhaust recirculation valve |
|
| 13A |
036131503R |
exhaust recirculation valve |
|
| 14 |
036131547 |
gasket |
|
| 15 |
N 0147404 |
allen key head bolt M6X16 |
|
| 16 |
054906267A |
valve |
|
| 17 |
037133843A |
filter |
|
| 18 |
N 0208231 |
die ring L12 |
|
| 19 |
N 10321901 |
union bolt M18X1,5X12 |
|
| 2 |
036133255E |
intermediate flange |
|
| 20 |
036131521N |
connecting pipe |
|
| 20A |
036131521AC |
connecting pipe |
|
| 21 |
036131550A |
gasket |
|
| 22 |
N 0147452 |
allen key head bolt M6X14 |
|
| 23 |
N 90413004 |
hexagonal head bolt 6X19 |
|
| 28 |
N 90434702 |
oval head panel screw E4,8X16 |
|
| 29 |
051133517 |
valve |
|
| 3 |
036133073 |
gasket 64X2,3X5,6 |
|
| 30 |
535133459 |
support ring |
|
| 33 |
N 10292201 |
spring-type clip A14X12 |
|
| 34 |
036131281 |
sealing plate |
|
| 35 |
036131818A |
adapter |
|
| 4 |
036129717E |
gasket 45X2,3X4,9 |
|
| 40 |
N 0230038 |
shouldered hex. nut, self-locking AM8 |
|
| 41 |
N 0147263 |
allen key head bolt M8X30 |
|
| 5 |
036133161C |
gasket |
|
| 6 |
036906051 |
thrust sensor |
|
| 7 |
036129720 |
locking cover |
|
| 8 |
036129530 |
non-return valve |
|
| 9 |
N 10404501 |
allen key head bolt M4X16 |
|
