Оригинальный
номер |
Название |
Заказ |
|
N 10417901B41 |
satin black |
|
| (7) |
070131512B |
exhaust gas recirc. cooler F 7L-4-066 001>>* |
|
| (9) |
070131063A |
throttle housing F 7L-4-066 001>>* |
|
| - |
074131547A |
gasket |
|
| 1 |
070128070C |
exhaust recirculation valve |
|
| 10 |
N 90200201 |
shouldered hex. nut, self-locking AM8 |
|
| 11 |
070131521R |
connecting pipe |
|
| 12 |
069131547D |
gasket 32MM |
|
| 13 |
N 10225401 |
hexagon socket head bolt with collar M8X20 |
|
| 14 |
070131521K |
connecting pipe |
|
| 15 |
070131548C |
pipe clip use if required: 074 131 547 A |
|
| 16 |
069131547D |
gasket 32MM |
|
| 17 |
N 10225401 |
hexagon socket head bolt with collar M8X20 |
|
| 18 |
N 0147047 |
cheese head bolt M6X20 |
|
| 19 |
N 01100624 |
hexagonal nut M6 |
|
| 2 |
07Z133557 |
gasket |
|
| 20 |
070131535A |
retaining panel |
|
| 21 |
N 10485701 |
bolt, with multi-spilne socket head M5X12-E-W |
|
| 22 |
N 90440706 |
hexagonal head bolt M6X15 |
|
| 23 |
7L6906131D |
retaining panel |
|
| 24 |
046130405 |
retaining plate |
|
| 25 |
046131887 |
grommet |
|
| 26 |
052129734 |
distance piece |
|
| 27 |
N 10248001 |
hexagon socket head bolt with collar M6X14 |
|
| 28 |
N 10417901 |
split rivet |
|
| 29 |
N 90666101 |
cable tie 4,5X200 |
|
| 3 |
1J0145769C |
retaining clip |
|
| 30 |
N 0150825 |
hexagon nut, shouldered M6 |
|
| 31 |
1J0906627C |
pressure converter |
|
| 32 |
7L6129482C |
vacuum hose |
|
| 33 |
046905291A |
non-return valve |
|
| 34 |
037133843A |
filter |
|
| 35 |
1J0906283C |
solenoid change-over valve |
|
| 36 |
7L6129482J |
vacuum hose |
|
| 37 |
N 10310001 |
clamp 9,4-11,9 |
|
| 38 |
7L6129482D |
vacuum hose |
|
| 39 |
7L6129482H |
vacuum hose |
|
| 4 |
N 10227803 |
allen key head bolt (combi) M6X20 |
|
| 40 |
7L6129482F |
vacuum hose |
|
| 41 |
N 10310001 |
clamp 9,4-11,9 |
|
| 42 |
7L6133798C |
vacuum hose |
|
| 43 |
1J0906627A |
pressure converter (for exhaust gas recirculation valve) |
|
| 44 |
7L6906131C |
retaining panel |
|
| 45 |
2D0906285G |
retainer |
|
| 46 |
038129807 |
damper |
|
| 47 |
7L6103811 |
retaining panel |
|
| 48 |
N 0138845 |
hexagon head panel screw 4,8X13 |
|
| 49 |
N 10156305 |
hexagon head bolt c/w shoulder M6X12 |
|
| 5 |
069131547D |
gasket 32MM |
|
| 50 |
4A0820199 |
double cable tie 7X213/140MM |
|
| 6 |
N 0195024 |
hexagon head bolt c/w shoulder M8X25 |
|
| 7 |
070131512 |
exhaust gas recirc. cooler F >> 7L-4-066 000* |
|
| 8 |
038131547 |
gasket |
|
| 9 |
070131063 |
throttle housing F >> 7L-4-066 000* |
|
