Оригинальный
номер |
Название |
Заказ |
| (21) |
J3610335024 |
transfer box housing for models with power take-off |
|
| (27) |
J9031132011 |
oil seal |
|
| (28) |
J3610735080 |
gearshift housing F >> 7A-M9510 000 |
|
| (28) |
J3610735140 |
gearshift housing F 7A-N9500 001>> |
|
| (30) |
J9011910337 |
bolt, hex. hd. with pin (combi) M10X1,25X130 |
|
| - |
AMV18820003 |
sealing paste 100G |
|
| - |
N 90107604 |
washer 8,2X18X2 |
|
| - |
N 0120387 |
spring ring 8 |
|
| 1 |
J9017920001 |
hexagon nut, self-locking VM20X1,5 |
|
| 10 |
N 0122293 |
spring washer A8X15X0,5 |
|
| 12 |
J3615335010 |
gasket |
|
| 13 |
J3614335010 |
gasket |
|
| 14 |
J3614135010 |
gasket |
|
| 15 |
J3613135010 |
bearing cover |
|
| 16 |
J9031248001 |
oil seal |
|
| 17 |
J3614535010 |
gasket |
|
| 18 |
J3611535010 |
cover for transmission case |
|
| 19 |
J9031138140 |
oil seal |
|
| 2 |
J9020120005 |
washer |
|
| 20 |
J3330935040 |
flange |
|
| 21 |
J3610335014 |
transfer box housing |
|
| 22 |
J9043018008 |
seal |
|
| 23 |
J9034118006 |
sealing plug |
|
| 24 |
J9034118057 |
drain plug |
|
| 25 |
J9025010232 |
parallel dowel pin |
|
| 26 |
J3614635021 |
gasket |
|
| 27 |
J9031132009 |
oil seal |
|
| 29 |
J9034130003 |
sealing plug |
|
| 3 |
J3330935030 |
flange |
|
| 30 |
J9011910186 |
hexagon head bolt (combi) M10X1,25X80 |
|
| 35 |
N 01024022 |
bolt, hexagon head self-locking M8X20MK |
|
| 36 |
N 90134001 |
spring washer 8X18X1,5 |
|
| 37 |
N 90179102 |
washer 8,2X18X3 |
|
| 39 |
J3314822010 |
reinforcement F >> 7A-N9500 063 |
|
| 4 |
J3332535020 |
protective plate |
|
| 40 |
J3316225010 |
gasket for models with power take-off |
|
| 41 |
J3316125010 |
cover for models with power take-off |
|
| 42 |
N 0102935 |
hexagonal head bolt M8X16 |
|
| 43 |
N 01224110 |
spring washer B8X15X0,8 |
|
| 44 |
J9011910128 |
hexagon head bolt (combi) M10X1,25X47 |
|
| 45 |
J9011910066 |
hexagon head bolt (combi) M10X1,25X37 |
|
| 46 |
J9011910130 |
hexagon head bolt (combi) M10X1,25X112 |
|
| 47 |
J3614735010 |
gasket |
|
| 48 |
J3612135010 |
cover |
|
| 49 |
N 01023911 |
hexagonal head bolt also use: M8X18 N 012 038 7 N 901 076 04 |
|
| 5 |
J3314530010 |
pressure washer |
|
| 6 |
J9030338010 |
dust cover |
|
| 7 |
J9031138016 |
oil seal |
|
| 8 |
J3613335010 |
bearing cover |
|
| 9 |
N 01024222 |
hexagonal head bolt M8X25 |
|
