Оригинальный
номер |
Название |
Заказ |
| (1) |
1C0809148B |
side member for wheel housing right upper front |
|
| (10) |
1C0809622 |
hinge reinforcement right lower |
|
| (11) |
1C0809623C |
hinge reinforcement F 9C-1-639 372>>* F 1C-1-466 070>>* left upper |
|
| (11) |
1C0809624C |
hinge reinforcement F 9C-1-639 372>>* F 1C-1-466 070>>* right upper |
|
| (11) |
1C0809624B |
hinge reinforcement F >> 9C-1-639 371* F >> 1C-1-639 371* right upper |
|
| (12) |
1C0809642A |
water drain channel right |
|
| (13) |
1C9809676A |
rip plate for side member *for new beetle rsi only * *original teile bestellung m.* *angabe der fg.-nummer und * *kopie des fahrzeugscheines * *bei volkswagen racing gmbh * *fax: (+49) 0511-... |
|
| (13) |
1C0809674 |
rip plate for side member right |
|
| (13) |
1C9809675A |
rip plate for side member *for new beetle rsi only * *original teile bestellung m.* *angabe der fg.-nummer und * *kopie des fahrzeugscheines * *bei volkswagen racing gmbh * *fax: (+49) 0511-... |
|
| (14) |
1C0809762C |
reinforcement for seat belt mounting point b-pillar F 9C-X-900 001>> F 1C-X-400 001>> right upper |
|
| (14) |
1C0809762 |
reinforcement for seat belt mounting point b-pillar F >> 9C-W-099 000 F >> 1C-W-099 000 right upper |
|
| (14) |
1C0809761C |
reinforcement for seat belt mounting point b-pillar F 9C-X-900 001>> F 1C-X-400 001>> left upper |
|
| (15) |
1C9809817 |
extension for side panel *for new beetle rsi only * *original teile bestellung m.* *angabe der fg.-nummer und * *kopie des fahrzeugscheines * *bei volkswagen racing gmbh * *fax: (+49) 0511-6... |
|
| (15) |
1C0809817C |
extension for side panel F 9C-X-900 001>>* F 1C-X-400 001>>* left inner |
|
| (15) |
1C9809818 |
extension for side panel *for new beetle rsi only * *original teile bestellung m.* *angabe der fg.-nummer und * *kopie des fahrzeugscheines * *bei volkswagen racing gmbh * *fax: (+49) 0511-6... |
|
| (15) |
1C0809818B |
extension for side panel F 9C-X-900 001>> F 1C-X-400 001>> right inner |
|
| (15) |
1C0809818A |
extension for side panel F >> 9C-W-099 000 F >> 1C-W-099 000 right inner |
|
| (16) |
1C0810422 |
side panel, inner reinforcement for fender right rear |
|
| (2) |
1C0809206 |
a-pillar, inner right lower |
|
| (3) |
1C0809262 |
reinforcement for pillar c right upper |
|
| (4) |
1C0809404B |
side panel, inner F >> 9C-W-099 000 F >> 1C-W-099 000 right rear |
|
| (4) |
1C0809403C |
side panel, inner F 9C-X-900 001>> 9C-1-615 000* F 1C-X-400 001>> 1C-1-430 000* left rear |
|
| (4) |
1C0809404C |
side panel, inner F 9C-X-900 001>> 9C-1-615 000* F 1C-X-400 001>> 1C-1-430 000* right rear |
|
| (4) |
1C0809404F |
side panel, inner F 9C-1-615 001>>* F 1C-1-430 001>>* right rear |
|
| (4) |
1C0809403E |
side panel, inner F 9C-1-615 001>>* F 1C-1-430 001>>* left rear |
|
| (4A) |
1C0813562D |
connecting piece right rear |
|
| (5) |
1C0809427B |
side panel, inner F 9C-1-615 001>>* F 1C-1-430 001>>* left front |
|
| (5) |
1C0809428A |
side panel, inner F 9C-1-615 001>>* F 1C-1-430 001>>* right front |
|
| (5) |
1C0809428 |
side panel, inner F 9C-X-900 001>> 9C-1-615 000* F 1C-X-400 001>> 1C-1-430 000* right front |
|
| (5) |
1C0809427 |
side panel, inner F 9C-X-900 001>> 9C-1-615 000* F 1C-X-400 001>> 1C-1-430 000* left front |
|
| (5) |
1C0809438A |
side panel, inner F >> 9C-W-099 000 F >> 1C-W-099 000 right front |
|
| (6) |
1C0809581B |
rip plate for side member F 9C-X-900 001>> 9C-1-615 000* F 1C-X-400 001>> 1C-1-430 000* left upper |
|
| (6) |
1C0809582H |
rip plate for side member F 9C-Y-607 009>> 9C-1-648 288 F 1C-Y-414 263>> 1C-1-475 633 right upper |
|
| (6) |
1C0809582G |
rip plate for side member F 9C-1-648 289>> F 1C-1-475 634>> right upper |
|
| (6) |
1C0809582B |
rip plate for side member F 9C-X-900 001>> 9C-Y-607 008* F 1C-X-400 001>> 1C-Y-414 262* right upper |
|
| (6) |
1C0809582A |
rip plate for side member F >> 9C-W-099 000 F >> 1C-W-099 000* right upper |
|
| (6) |
1C0809581G |
rip plate for side member F 9C-1-615 001>> F 1C-1-430 001>> left upper |
|
| (7) |
1C0809598 |
rip plate for side member right |
|
| (8) |
1C0809606B |
side panel F >> 1C-W-032 548* use if required: right outer N 908 895 01 N 908 148 01 |
|
| (8) |
1C0809604C |
side panel F 9C-X-900 001>>* F 1C-X-400 001>>* right outer |
|
| (8) |
1C9809604 |
side panel *for new beetle rsi only * *original teile bestellung m.* *angabe der fg.-nummer und * *kopie des fahrzeugscheines * *bei volkswagen racing gmbh * *fax: (+49) 0511-67 49 439 * right outer |
|
| (8) |
1C0809604A |
side panel F >> 9C-W-099 000 F 1C-W-032 549>> 1C-W-099 000 right outer |
|
| (8) |
1C9809603 |
side panel *for new beetle rsi only * *original teile bestellung m.* *angabe der fg.-nummer und * *kopie des fahrzeugscheines * *bei volkswagen racing gmbh * *fax: (+49) 0511-67 49 439 * left outer |
|
| (8) |
1C0809603A |
side panel F >> 9C-W-099 000 F 1C-W-432 549>> 1C-W-099 000 left outer |
|
| (8) |
1C0809603B |
side panel F 9C-X-900 001>> 9C-1-640 539* F 1C-X-400 001>> 1C-1-449 521* left outer |
|
| (8) |
1C0809603C |
side panel F 9C-1-640 540>>* F 1C-1-449 522>>* left outer |
|
| (9) |
1C0809607C |
reinforcement for pillar b F 9C-X-900 001>> F 1C-X-400 001>> left |
|
| (9) |
1C0809608 |
reinforcement for pillar b F >> 9C-W-099 000 F >> 1C-W-099 000 right |
|
| (9) |
1C0809608B |
reinforcement for pillar b F 9C-X-900 001>> F 1C-X-400 001>> right |
|
| - |
N 90889501 |
gewindebolzen M6X17-GK |
|
| - |
N 90889501 |
gewindebolzen M6X17-GK |
|
| - |
N 90814801 |
welded nut M6 |
|
| - |
N 90814801 |
welded nut M6 |
|
| 1 |
1C0809147B |
side member for wheel housing left upper front |
|
| 10 |
1C0809621 |
hinge reinforcement left lower |
|
| 11 |
1C0809623B |
hinge reinforcement F >> 9C-1-639 371* F >> 1C-1-466 069* left upper |
|
| 12 |
1C0809641A |
water drain channel left |
|
| 13 |
1C0809673 |
rip plate for side member left |
|
| 14 |
1C0809761 |
reinforcement for seat belt mounting point b-pillar F >> 9C-W-099 000 F >> 1C-W-099 000 left upper |
|
| 15 |
1C0809817A |
extension for side panel F >> 9C-W-099 000 F >> 1C-W-099 000 left inner |
|
| 16 |
1C0810421 |
side panel, inner reinforcement for fender left rear |
|
| 2 |
1C0809205 |
a-pillar, inner left lower |
|
| 3 |
1C0809261 |
reinforcement for pillar c left upper |
|
| 4 |
1C0809403B |
side panel, inner F >> 9C-W-099 000 F >> 1C-W-099 000 left rear |
|
| 4A |
1C0813561D |
connecting piece left rear |
|
| 5 |
1C0809437A |
side panel, inner F >> 9C-W-099 000 F >> 1C-W-099 000 left front |
|
| 6 |
1C0809581A |
rip plate for side member F >> 9C-W-099 000 F >> 1C-W-099 000 left upper |
|
| 7 |
1C0809597 |
rip plate for side member left |
|
| 8 |
1C0809605D |
side panel F >> 1C-W-032 548* use if required: left outer N 908 895 01 N 908 148 01 |
|
| 9 |
1C0809607 |
reinforcement for pillar b F >> 9C-W-099 000 F >> 1C-W-099 000 left |
|
