Оригинальный
номер |
Название |
Заказ |
| (1) |
045131501C |
exhaust recirculation valve |
|
| (10) |
1J0906627A |
pressure converter (for turbocharger) F 9C-Y-600 001>> |
|
| (14) |
046130405 |
retaining plate |
|
| (14) |
1C0906483A |
retaining panel |
|
| (17) |
113127563 |
t-piece 5/5/5 |
|
| (19) |
038131524 |
holder for vacuum hose use if required: N 901 063 02 |
|
| (1A) |
038131513 |
exhaust gas recirc. cooler |
|
| (22) |
038103945A |
retaining panel |
|
| (27) |
034133784 |
angled hose 3,5MM |
|
| (2A) |
038131521F |
connecting pipe |
|
| (2B) |
038131521E |
connecting pipe |
|
| (39) |
1J0906283C |
solenoid change-over valve F 9C-Y-600 001>> use if required: 038 131 529 |
|
| (9) |
1J0906627 |
pressure converter (for exhaust gas recirculation valve) F 9C-Y-600 001>> |
|
| - |
N 0202821 |
hose in coils of 5m order unit 5 5X3 |
|
| - |
038131529 |
retaining panel |
|
| - |
N 0203535 |
hose in coils of 5m order unit 5 3,5X2 |
|
| - |
N 0202821 |
hose in coils of 5m order unit 5 5X3 |
|
| - |
N 0203535 |
hose in coils of 5m order unit 5 3,5X2 |
|
| - |
N 0203535 |
hose in coils of 5m order unit 5 3,5X2 |
|
| 10 |
1H0906627A |
pressure converter (for turbocharger) F >> 9C-X-999 000 |
|
| 11 |
N 90106302 |
hexagon nut, shouldered M6 |
|
| 12 |
052129734 |
distance piece |
|
| 13 |
046131887 |
grommet |
|
| 15 |
046905291A |
non-return valve |
|
| 16 |
06A133382K |
joint pipe 4X6 |
|
| 17 |
113201943B |
t-piece 4/4/4 |
|
| 19 |
N 0209022 |
cable tie 6X246 |
|
| 1A |
038131513 |
exhaust gas recirc. cooler |
|
| 2 |
038131521J |
connecting pipe |
|
| 20 |
7M0129808 |
damper |
|
| 21 |
N 0139681 |
oval head panel screw ST4,8X13-C |
|
| 23 |
N 0245281 |
pipe clip LC8-12 |
|
| 24 |
034133784 |
angled hose 3,5MM |
|
| 26 |
034133784 |
angled hose 3,5MM |
|
| 2A |
038131521F |
connecting pipe |
|
| 2B |
038131521E |
connecting pipe |
|
| 38 |
056129971 |
y-piece 4/4/4 |
|
| 39 |
1J0906283A |
solenoid change-over valve F >> 9C-X-999 000 use if required: 038 131 529 |
|
| 3A |
069131547D |
gasket 32MM |
|
| 3B |
N 90521601 |
round seal 55X3-N |
|
| 4A |
038131547A |
gasket |
|
| 5 |
N 90200201 |
shouldered hex. nut, self-locking AM8 |
|
| 6 |
N 10115402 |
allen key head bolt (combi) M6X18-Z1 |
|
| 6A |
N 0903582 |
allen key head bolt (combi) M6X12 |
|
| 6B |
N 90415403 |
allen key head bolt (combi) M8X22-Z1 |
|
| 6C |
N 90771601 |
allen key head bolt (combi) M6X20-Z1 |
|
| 7 |
N 0903151 |
hexagon head bolt (combi) M8X25-Z3 |
|
| 9 |
1H0906627 |
pressure converter (for exhaust gas recirculation valve) F >> 9C-X-999 000 |
|
