Оригинальный
номер |
Название |
Заказ |
|
155867243 GF9 |
black/chrome |
|
|
155867243 GF9 |
black/chrome |
|
|
321867269A 01C |
satin black |
|
|
147867241 01C |
satin black |
|
|
321867241E 95U |
alum metallic replacement: 147 867 241 (01C) 281 957 087 |
|
|
321867241E 01C |
satin black replacement: 147 867 241 (01C) 281 957 087 |
|
|
154867243 GF9 |
black/chrome |
|
|
172857368 01C |
satin black |
|
|
161857084 01C |
satin black |
|
|
172857003D 8BM |
satin black |
|
|
171857003D 8BM |
satin black |
|
|
171857003D 8BM |
satin black |
|
| (11) |
172857368 |
cap for instrument panel opening rhd |
|
| (14) |
147867241 |
trim F 16-B-000 001>> F 17-B-000 001>> use if required: lhd lhd 281 957 087 left |
|
| (19) |
154867243 |
trim rhd |
|
| (2) |
171857003D |
dashboard, padded for models with passive restraint system lhd |
|
| (2) |
172857003D |
dashboard rhd |
|
| (22) |
172867256 |
trim for switch right rhd |
|
| (23) |
172867255 |
trim for switch left rhd |
|
| (23) |
172867255A |
trim for switch for models with fader control left rhd |
|
| (23) |
171867256A |
trim for switch for models with fader control right lhd |
|
| (24A) |
281957087 |
blind cover 43,5X27MM |
|
| (25) |
321957087 |
blind cover for padded dashboard |
|
| - |
281957087 |
blind cover 43,5X27MM |
|
| - |
171857461C |
trim for air vent 64,5MM |
|
| - |
171857461B |
trim for air vent 112 MM |
|
| 10 |
161857367 |
cap for instrument panel opening lhd |
|
| 12 |
N 90097901 |
washer 4,5X21X4 |
|
| 13 |
N 01396626 |
oval head panel screw 4,2X13STC |
|
| 14 |
321867241E |
trim F 16-B-000 001>> F 17-B-000 001>> lhd lhd |
|
| 15 |
N 0154381 |
snap nut ST3,5X16,75X11 |
|
| 16 |
N 0115213 |
washer A3,7X8X0,5 |
|
| 17 |
N 0139587 |
oval head panel screw ST3,5X13-C |
|
| 18 |
321867269A |
cover cap |
|
| 19 |
155867243 |
trim lhd |
|
| 19 |
155867243 |
trim for models with passive restraint system lhd |
|
| 19A |
N 0154381 |
snap nut ST3,5X16,75X11 lhd |
|
| 2 |
171857003D |
dashboard, padded lhd |
|
| 20 |
N 0115213 |
washer A3,7X8X0,5 |
|
| 21 |
N 0139587 |
oval head panel screw ST3,5X13-C |
|
| 22 |
171867255 |
trim for switch left lhd |
|
| 23 |
171867256 |
trim for switch right lhd |
|
| 24 |
171919079A |
blind cover |
|
| 24A |
321919079A |
blind cover |
|
| 25 |
861957087 |
blind cover |
|
| 3 |
N 0138851 |
hexagon head panel screw B4,8X25 |
|
| 4 |
N 01152318 |
washer A5,3X10X1 |
|
| 5 |
161857084 |
washer |
|
| 6 |
N 0154361 |
snap nut ST4,8X15X16,2 |
|
| 7 |
N 01152318 |
washer A5,3X10X1 |
|
| 8 |
N 0139649 |
oval head panel screw ST4,2X16-C |
|
| 9 |
161857289 |
clips for padded dashboard |
|
| c |
161857367 01C |
satin black |
|
