Оригинальный
номер |
Название |
Заказ |
|
191881477 LX6 |
satin black |
|
|
171881671 041 |
schwarz |
|
|
191881633 01C |
satin black |
|
|
171881478C 01C |
satin black |
|
|
191881478 LX6 |
satin black |
|
|
191881633 LX5 |
satin black replacement: 191 881 633 (01C) |
|
|
191881634 01C |
satin black |
|
|
113881633E 01C |
satin black |
|
|
191881633A 01C |
satin black |
|
|
171881500 01C |
satin black |
|
|
191881607 01C |
satin black |
|
|
171881477C 01C |
satin black |
|
|
371881607 01C |
satin black |
|
|
191881671 01C |
satin black |
|
|
191881479 LX6 |
satin black |
|
|
171881479B 01C |
satin black |
|
|
171881939A 01C |
satin black |
|
|
191881480 LX6 |
satin black |
|
| (13) |
191881595 |
wire cable 370MM outer |
|
| (15) |
191881607 |
trim F 16-E-061 574>>* F 17-D-649 388>>* F 17-E-061 574>>* 2 doors |
|
| (17) |
191881633 |
knob for models with passive restraint system F 16-E-061 574>>* F 17-D-049 388>>* F 17-E-061 574>>* |
|
| (17) |
191881634 |
knob F 16-E-061 574>>* F 17-D-049 388>>* F 17-E-061 574>>* right 2 doors |
|
| (17) |
191881633A |
knob F 16-E-061 574>>* F 17-D-649 388>>* F 17-E-061 574>>* left 2 doors |
|
| (19) |
191881671 |
adjustment knob F 16-E-061 574>>* F 17-D-649 389>>* F 17-E-061 574>>* |
|
| (5) |
191881479 |
trim with hole F 16-E-061 574>>* F 17-D-649 389>>* F 17-E-061 574>>* left |
|
| (5) |
171881480B |
trim with hole F >> 16-E-061 573* F >> 17-D-649 388* F >> 17-E-061 573* right |
|
| (5) |
191881480 |
trim with hole F 16-E-061 574>>* F 17-D-649 389>>* F 17-E-061 574>>* right |
|
| (6) |
191881478 |
trim without hole F 16-E-061 574>>* F 17-D-649 389>>* F 17-E-061 574>>* right |
|
| (6) |
191881477 |
trim without hole F 16-E-061 574>>* F 17-D-649 389>>* F 17-E-061 574>>* left |
|
| (6) |
171881477C |
trim without hole F >> 16-E-061 573* F >> 17-D-649 388* F >> 17-E-061 573* left |
|
| (7) |
191881493 |
spacer ring F 16-E-061 574>>* F 17-D-649 389>>* F 17-E-061 574>>* |
|
| (9) |
191881499 |
dished washer F 16-E-061 574>>* F 17-D-649 389>>* F 17-E-061 574>>* |
|
| - |
N 0141201 |
fillister hd. bolt F 16-E-061 574>>* F 17-D-649 389>>* F 17-E-061 574>>* M4X12 |
|
| - |
823881621A |
guide F 16-E-061 574>>* F 17-D-649 389>>* F 17-E-061 574>>* |
|
| 1 |
811881049D |
backrest frame F 16-E-061 574>> F 17-D-649 389>> F 17-E-061 574>> use if required: 191 881 477 (LX6) 191 881 478 (LX6) 191 881 479 (L |
|
| 10 |
N 0102085 |
hexagonal head bolt M6X8 |
|
| 11 |
N 0121272 |
shake-proof washer A6,4 |
|
| 12 |
171881500 |
grip pin |
|
| 13 |
171881595C |
wire cable 363MM outer |
|
| 14 |
171881596D |
wire cable 765MM inner |
|
| 15 |
371881607 |
trim F >> 16-E-061 573* F >> 17-D-649 388* F >> 17-E-061 573* 2 doors |
|
| 16 |
171881619 |
tension spring |
|
| 17 |
113881633E |
knob F >> 16-E-061 573* F >> 17-D-649 388* F >> 17-E-061 573* 2 doors |
|
| 18 |
443881743 |
clip for guide |
|
| 19 |
171881671 |
adjustment knob F >> 16-E-061 573* F >> 17-D-649 388* F >> 17-E-061 573* |
|
| 20 |
171881687 |
retaining plate f. rotary knob |
|
| 21 |
321881713 |
protective cover |
|
| 23 |
811881777A |
padding center |
|
| 24 |
171881775AP |
padding for backrest |
|
| 25 |
171881775AM |
padding for backrest |
|
| 3 |
311881247 |
clip 2 doors |
|
| 30 |
191881903C |
head restraint, adjustable |
|
| 32 |
113881451 |
slide for zip fastener 6,4 |
|
| 34 |
171881939A |
guide for head restraint, adjustable |
|
| 35 |
. |
discontinued / replacement: single parts |
|
| 4 |
N 90052702 |
lock washer 8 |
|
| 5 |
171881479B |
trim with hole F >> 16-E-061 573* F >> 17-D-649 388* F >> 17-E-061 573* left |
|
| 6 |
171881478C |
trim without hole F >> 16-E-061 573* F >> 17-D-649 388* F >> 17-E-061 573* right |
|
| 7 |
171881493 |
spacer ring F >> 16-E-061 573* F >> 17-D-649 388* F >> 17-E-061 573* |
|
| 8 |
171881497 |
tension spring |
|
| 9 |
171881499 |
dished washer F >> 16-E-061 573* F >> 17-D-649 388* F >> 17-E-061 573* |
|
| c |
171881480B 01C |
satin black |
|
