Оригинальный
номер |
Название |
Заказ |
|
171867149 01C |
satin black |
|
|
161971913 581 |
cloud white |
|
|
311867169 01C |
satin black |
|
|
161867172A 01C |
satin black |
|
|
311867169 01C |
satin black |
|
|
311867169 01C |
satin black |
|
|
111867171D 041 |
schwarz |
|
|
171867150 01C |
satin black |
|
|
311867649 01C |
satin black |
|
|
171867134 01C |
satin black replacement: 171 867 134 A (01C) |
|
|
801867299 01C |
satin black |
|
|
171867134A 01C |
satin black |
|
| (4A) |
171867134A |
storage box right |
|
| (4B) |
171867149 |
loudspeaker grille left |
|
| - |
N 0139655 |
oval head panel screw B4,2X9,5 |
|
| - |
311867167 |
oval head panel screw for models with precut headlining 4,2X13 |
|
| - |
N 0140872 |
oval hd. csk. self-tapp. screw ST3,5X16-C |
|
| - |
N 0115227 |
washer A4,3X9X0,8 |
|
| - |
311867169 |
cap for screw for models with precut headlining 2 doors |
|
| 10 |
3A0867201H |
protective foil sound absorber adapt with workshop equipment use if required: also use: 1100X600X2 D 469 101 A3 3A0 035 217 |
|
| 11 |
N 0115227 |
washer A4,3X9X0,8 |
|
| 12 |
311867167 |
oval head panel screw 4,2X13 |
|
| 13 |
311867169 |
cap for screw |
|
| 14 |
111867171D |
pull handle 2 doors 4-tuerig |
|
| 15 |
111867199 |
expanding nut 2 doors 4-tuerig |
|
| 16 |
N 0139461 |
oval head panel screw B6,3X32 2 doors 4-tuerig |
|
| 17 |
N 0139671 |
oval head panel screw B4,2X19-C 2 doors 4-tuerig |
|
| 18 |
171711965 |
seal 18X6X4 2 doors 4-tuerig |
|
| 20 |
155867199 |
expanding nut |
|
| 21 |
N 0139461 |
oval head panel screw B6,3X32 2 doors 4-tuerig |
|
| 21 |
161867172A |
armrest right |
|
| 21B |
161867197 |
cap lhd |
|
| 21C |
161867199 |
clips lhd |
|
| 25 |
801867299 |
clip |
|
| 26 |
823867299 |
clip |
|
| 26B |
161971913 |
grommet |
|
| 28 |
171867365B |
beading 2 doors 4-tuerig |
|
| 37 |
171867535A |
tensioning wire |
|
| 38 |
171867549 |
clips |
|
| 39 |
311867649 |
cap |
|
| 4 |
. |
discontinued / replacement: 171 867 133 171 867 149 or 171 867 134 171 867 150 |
|
| 41 |
331867807 |
sound insulation for roof |
|
| 4A |
171867134 |
storage box right |
|
| 4B |
171867150 |
loudspeaker grille right |
|
| 4C |
N 01396626 |
oval head panel screw 4,2X13STC |
|
| 5 |
803867169 |
washer |
|
| 6 |
N 0139649 |
oval head panel screw ST4,2X16-C |
|
| 7 |
311867167 |
oval head panel screw 4,2X13 |
|
| 8 |
311867169 |
cap for screw |
|
| c |
171867365B 041 |
schwarz |
|
