Оригинальный
номер |
Название |
Заказ |
|
3B0837111 B41 |
satin black |
|
| (1) |
1H4831055 |
door also use: left *>>1H-V-100000 1H0 837 798 N 020 024 1 |
|
| (1) |
1H4831056 |
door also use: right *>>1H-V-100000 1H0 837 798 N 020 024 1 |
|
| (12) |
1H0837249A |
check rod - door front |
|
| (21) |
1H4831513 |
side reinforcement 4-tuerig left lower |
|
| (24) |
1H4837965 |
impact profile for models with side airbag left 4-tuerig |
|
| (3) |
1H0831403 |
hinge half left |
|
| (4) |
1H0831410A |
mounting plate for door hinge right lower |
|
| (4) |
1H0831410B |
mounting plate for door hinge right upper |
|
| (4) |
1H0831409A |
mounting plate for door hinge left lower |
|
| (4) |
1H0831409D |
mounting plate for door hinge left upper |
|
| - |
323863950 |
sound absorber (self-adhesive) order unit 6 550X250X2 |
|
| - |
3B0837111 |
plug 16 |
|
| - |
1H0837947 |
cover cap black |
|
| 10 |
N 90594502 |
torx socket head combi-bolt M8X18-H |
|
| 11 |
191837865 |
cover cap |
|
| 12 |
1H0837249 |
check rod - door |
|
| 13 |
N 90533002 |
hexagon head bolt (combi) M6X20 |
|
| 14 |
1H0837257 |
pin |
|
| 15 |
1H0837267 |
covering |
|
| 16 |
191837270 |
hexagon nut, shouldered M5 |
|
| 17 |
1H0837323 |
boot |
|
| 18 |
1H3867365D |
door seal, inner shorten if necessary 3770MM |
|
| 19 |
1H0971916B |
bellows 48,5/36/66 |
|
| 20 |
357971908A |
plug 49,5 |
|
| 21 |
1H4831514 |
side reinforcement 4-tuerig right lower |
|
| 22 |
N 90770301 |
torx socket head combi-bolt M10X18-H |
|
| 23 |
N 90594502 |
torx socket head combi-bolt M8X18-H |
|
| 24 |
1H4837966 |
impact profile for models with side airbag right 4-tuerig |
|
| 25 |
N 90566602 |
torx socket fillister hd. bolt M6X16-H-V |
|
| 26 |
1H0837798 |
plug front |
|
| 27 |
N 0200241 |
plug INNEN UNTEN AN INNENBLECH A10X1 |
|
| 28 |
N 0200241 |
plug A10X1 |
|
| 3 |
1H0831404 |
hinge half right |
|
| 5 |
N 90355503 |
threaded pin M8X12 |
|
| 7 |
N 90527101 |
torx socket head combi-bolt M8X24-H-V |
|
| 8 |
N 90556401 |
torx socket head combi-bolt HM8X33-V |
|
| 9 |
1H4831505A |
side reinforcement |
|
