Оригинальный
номер |
Название |
Заказ |
|
3B0837111 B41 |
satin black |
|
| (1) |
1H4833055 |
door left |
|
| (1) |
1H9833055A |
door left |
|
| (1) |
1H9833056A |
door right |
|
| (13) |
3B0837111 |
plug 16 |
|
| (18) |
1H4839281A |
retainer bracket check rod - door left rear |
|
| (21) |
1H9867367D |
door seal, inner F 1H-T-240 001>>* shorten if necessary rear, inner 3320MM |
|
| (3) |
1H0831403 |
hinge half left |
|
| (4) |
1H4833409 |
mounting plate for door hinge left |
|
| (9) |
1H4833505A |
side reinforcement left |
|
| - |
D 185400A2 |
liquid sealant 10ML |
|
| - |
323863950 |
sound absorber (self-adhesive) order unit 6 550X250X2 |
|
| - |
1H4898311 |
repair plate door inner part |
|
| - |
1H0837947 |
cover cap black |
|
| - |
1H4839633 |
arrester pin |
|
| - |
1H0839863 |
sealing side panel 25 |
|
| 1 |
1H4833056 |
door right |
|
| 10 |
N 90594502 |
torx socket head combi-bolt M8X18-H |
|
| 11 |
8A0831449 |
plug 14 |
|
| 12 |
171957857 |
plug 28 |
|
| 14 |
1H4839249 |
check rod - door |
|
| 15 |
N 90533002 |
hexagon head bolt (combi) M6X20 |
|
| 16 |
1H4839257C |
pin |
|
| 17 |
1H4839267 |
covering |
|
| 18 |
1H4839282 |
retainer bracket check rod - door right rear |
|
| 19 |
N 90533002 |
hexagon head bolt (combi) also use: M6X20 D 185 400 A2 |
|
| 20 |
1H4839323 |
boot |
|
| 21 |
1H3867365D |
door seal, inner F >> 1H-T-240 000* shorten if necessary 3770MM |
|
| 22 |
1H4971611A |
bellows |
|
| 23 |
1H4971908 |
plug 64 |
|
| 3 |
1H0831404 |
hinge half right |
|
| 4 |
1H4833410 |
mounting plate for door hinge right |
|
| 5 |
N 90355503 |
threaded pin M8X12 |
|
| 7 |
N 90527101 |
torx socket head combi-bolt M8X24-H-V |
|
| 8 |
N 90556401 |
torx socket head combi-bolt HM8X33-V |
|
| 9 |
1H4833506A |
side reinforcement right |
|
