Оригинальный
номер |
Название |
Заказ |
|
1H0837248H F31 |
mauritius blue |
|
|
1H0837226 B41 |
satin black |
|
|
1H0837226 T21 |
beaver |
|
|
1H0837225 Y01 |
flint grey |
|
|
1H0837225 C82 |
soft black frosted |
|
|
1H0837225 B41 |
satin black |
|
|
1H0837225 T21 |
beaver |
|
|
3B0837111 B41 |
satin black |
|
|
1H0837244 9ZS |
black/silver |
|
|
1H0837207C 3FZ |
satin black |
|
|
1H0837187A 01C |
satin black |
|
|
1H0837226 C82 |
soft black frosted |
|
|
1H0837226 Y01 |
flint grey |
|
|
1H0837248H B41 |
satin black |
|
|
1H0837248G B41 |
satin black |
|
|
1H0837248F T21 |
beaver |
|
|
1H0837248F B41 |
satin black |
|
|
1H0837247H B41 |
satin black |
|
|
1H0837247G B41 |
satin black |
|
|
1H0837247F T21 |
beaver |
|
|
1H0837247F F31 |
mauritius blue |
|
|
1H0837247F B41 |
satin black |
|
|
1H0837247G F31 |
mauritius blue |
|
|
1H0837207B 3FZ |
satin black |
|
| (1) |
1H2837016M |
door lock for vehicles with central locking system right rhd |
|
| (1) |
1H1837015N |
door lock for vehicles with central locking system left lhd |
|
| (1) |
1H1837016L |
door lock right lhd |
|
| (1) |
1H1837015M |
door lock left lhd |
|
| (1) |
1H2837015J |
door lock for vehicles with central locking system also use: left rhd 8D0 862 245 |
|
| (1) |
1H2837015H |
door lock left rhd |
|
| (1) |
1H1837015P |
door lock for models without central locking for models with electrically operated windows left lhd |
|
| (1) |
1H2837016L |
door lock right rhd |
|
| (1) |
1H1837015N |
door lock for vehicles with central locking system for models with electrically operated windows left lhd |
|
| (1) |
1H2837016N |
door lock for models without central locking for models with electrically operated windows right rhd |
|
| (11) |
1H4837183 |
locking rod for door lock left |
|
| (14) |
1H4837193A |
pull rod left 4-tuerig |
|
| (20) |
1H0837207C |
door handle, outer right |
|
| (20) |
1H0837207B |
door handle, outer left |
|
| (24) |
1H0837237A |
driver (drivers side) |
|
| (27) |
1H0837061G |
lock cylinder for door handle without tumblers and key for lock combination numbers: 1-1000,2001-3000,4001-6000, 7101-8154 also use: SYSTEM A 1H0 837 223 B 1H0 837 237 D |
|
| (27) |
1H0837061H |
lock cylinder for door handle without tumblers and key for lock combination numbers: 1001-2000,3001-4000,6001-7086, 8201-9282 use if required: SYSTEM B 1H0 837 223 B 1H0 837 237 D |
|
| (3) |
1H2962103 |
micro switch for vehicles with central locking system for models with electrically operated windows rhd |
|
| (33) |
6N0837219 |
main key with fixed code transponder profile ah quote key number for cut keys |
|
| (34) |
1H0837219A |
main key with light and fixed code transponder profile ah quote key number for cut keys |
|
| (41) |
1H0837225 |
door inner operating lever left |
|
| (42) |
1H0837141 |
interior release lever housing left |
|
| (43) |
1H0837248H |
trim for models with electrically operated windows right lhd |
|
| (43) |
1H0837247F |
trim with opening for rear view mirror adjustment left |
|
| (43) |
1H0837248G |
trim with opening for rear view mirror adjustment right rhd electric |
|
| (43) |
1H0837247G |
trim with opening for rear view mirror adjustment left lhd electric |
|
| (43) |
1H0837247H |
trim for models with electrically operated windows left rhd |
|
| - |
G 052778A2 |
lock cylinder lubricant spray servicing materials 50ML |
|
| - |
1H0837244 |
emblem |
|
| 1 |
1H1837016M |
door lock for vehicles with central locking system for models with electrically operated windows right lhd |
|
| 1 |
1H1837016M |
door lock for vehicles with central locking system right lhd |
|
| 10 |
3B0837111 |
plug 16 |
|
| 11 |
1H4837184 |
locking rod for door lock right |
|
| 12 |
1H0837187A |
knob for locking rod |
|
| 14 |
1H4837194A |
pull rod right 4-tuerig |
|
| 15 |
321837199 |
clip |
|
| 18 |
1H0837209 |
base front |
|
| 19 |
1H0837211B |
base rear |
|
| 21 |
1H0837223B |
excentric also use: 1H0 837 237 D 1H0 837 061 G 1H0 837 061 H |
|
| 22 |
1H0837227 |
seal |
|
| 23 |
1H0837229B |
pressure spring |
|
| 24 |
1H0837237D |
driver (passenger side) also use: 1H0 837 061 G 1H0 837 061 H 1H0 837 223 B |
|
| 25 |
1H0837245 |
torsion spring |
|
| 26 |
443898041A |
1 set: tumbler plates for lock cylinder 13,5MM |
|
| 3 |
1H0962103 |
micro switch for vehicles with central locking system for models with electrically operated windows lhd |
|
| 30 |
N 90598804 |
torx socket fillister hd. bolt M6X12-H |
|
| 31 |
357837242 |
clips |
|
| 33 |
357837219A |
main key profile ah quote key number for cut keys |
|
| 35 |
N 90314501 |
bulb 1,5V/0,09A |
|
| 36 |
N 90262401 |
micro-cell battery 1,5V |
|
| 41 |
1H0837226 |
door inner operating lever right |
|
| 42 |
1H0837142 |
interior release lever housing right |
|
| 43 |
1H0837248F |
trim with opening for rear view mirror adjustment right |
|
| 6 |
N 90598804 |
torx socket fillister hd. bolt M6X12-H |
|
| 7 |
1H0837034C |
striker plate |
|
| 8 |
N 10234901 |
oval head countersunk bolt M8X22 |
|
| 9 |
6N0809237 |
threaded plate |
|
