Оригинальный
номер |
Название |
Заказ |
| (10) |
1H5803502D |
side member with reinforcement and welded nut right rear |
|
| (10) |
1H9803502A |
side member with reinforcement and welded nut right rear |
|
| (10) |
1H9803501A |
side member with reinforcement and welded nut left rear |
|
| (11) |
1H0803505A |
longitudinal member left rear |
|
| (12) |
1H9803513 |
mounting for rear axle beam left |
|
| (12) |
1H0803514 |
mounting for rear axle beam right |
|
| (12) |
1H9803514 |
mounting for rear axle beam right |
|
| (13) |
1H9803531 |
cross member |
|
| (14) |
1H9803535 |
mounting plate exhaust silencer, rear |
|
| (17) |
1H5803611 |
towing eye rear |
|
| (17) |
1H9803611 |
towing eye rear |
|
| (17A) |
1H9803721 |
cover for spare wheel well |
|
| (1B) |
1H9803417A |
side panel left lower inner |
|
| (2) |
1H5803417 |
wheel housing left rear |
|
| (20) |
1H9803611 |
towing eye bumper bracket rear |
|
| (24A) |
861803899B |
nut for spare wheel mounting for spare wheel with normal tire and raised boot floor |
|
| (3) |
1H0803427 |
mounting for vehicles with three-point seat belts, rear left |
|
| (4) |
1H9803436 |
wheel housingliner right outer |
|
| (4) |
1H9803435 |
wheel housingliner left outer |
|
| (4) |
1H0803435 |
wheel housingliner left outer |
|
| (5) |
1H9803448 |
mounting for backrest right upper |
|
| (5) |
1H9803447 |
mounting for backrest left upper |
|
| (5) |
1H0803449A |
mounting for backrest left upper |
|
| (6) |
1H0803478A |
reinforcement for jack socket right |
|
| (8) |
1H9803661 |
reinforcement for side member left rear |
|
| (8) |
1H0803566 |
reinforcement for side member right rear |
|
| (8) |
1H9803662 |
reinforcement for side member right rear |
|
| (9) |
1H9803492 |
connecting plate for longitudinal member right rear |
|
| (9) |
1H9803491 |
connecting plate for longitudinal member left rear |
|
| (9) |
1H5803491 |
connecting plate for longitudinal member left rear |
|
| (9A) |
1H9804739 |
bracket for bumper rear |
|
| (9B) |
1H5803507 |
side panel, inner left lower |
|
| - |
803803583B |
plug 40 |
|
| - |
N 10226501 |
plug A30 |
|
| - |
N 90437401 |
pop-rivet A4,8X10 |
|
| - |
N 90436101 |
locking cover 20X33 |
|
| - |
N 90402801 |
locking cover tie-down eye 16,5X32,5X18 |
|
| - |
1H5804993 |
mounting for trailer coupling ball |
|
| - |
333803737 |
rotary fastener |
|
| 10 |
1H5803501D |
side member with reinforcement and welded nut left rear |
|
| 11 |
1H0803506A |
longitudinal member right rear |
|
| 12 |
1H0803513 |
mounting for rear axle beam left |
|
| 13 |
1H0803531 |
cross member |
|
| 14 |
1H0803535A |
mounting plate exhaust silencer, rear |
|
| 15 |
191803545 |
bracket for exhaust silencer left rear |
|
| 16 |
411803595 |
cover 136MM |
|
| 19 |
191803746 |
bracket for strap right rear |
|
| 1A |
357803272 |
bracket for spare wheel |
|
| 1A |
1H9803181 |
cross member under luggag.boot rear |
|
| 1B |
1H9803418A |
side panel right lower inner |
|
| 2 |
1H5803418 |
wheel housing right rear |
|
| 20 |
1H9804937 |
bracket for bumper left lower |
|
| 21 |
6X0803959 |
cover for sender unit |
|
| 22 |
321803963 |
seal |
|
| 23 |
N 0139655 |
oval head panel screw B4,2X9,5 |
|
| 24 |
191803899 |
nut for spare wheel mounting for temporary spare wheel |
|
| 25 |
191898335 |
connecting strut for floor plate |
|
| 26 |
N 0105682 |
welded bolt order unit 100 AM8X22 |
|
| 27 |
N 01155811 |
washer 8,4X15X1,6 |
|
| 28 |
N 10034401 |
plug 30X5,6X37 |
|
| 29 |
N 90074401 |
hexagon nut, self-locking M8 |
|
| 3 |
1H0803428 |
mounting for vehicles with three-point seat belts, rear right |
|
| 30 |
N 90175701 |
weld pin order unit 100 5X12 |
|
| 31 |
D 003500 |
long-life underseal 1.0 ltr. |
|
| 4 |
1H0803436 |
wheel housingliner right outer |
|
| 5 |
1H0803450A |
mounting for backrest right upper |
|
| 6 |
1H0803477A |
reinforcement for jack socket left |
|
| 7 |
191803483 |
housing for fuel filler neck |
|
| 8 |
1H0803565 |
reinforcement for side member left rear |
|
| 9 |
1H5803492 |
connecting plate for longitudinal member right rear |
|
| 9A |
1H5804739 |
bracket for bumper rear |
|
| 9B |
1H5803508 |
side panel, inner right lower |
|
