Оригинальный
номер |
Название |
Заказ |
| (1) |
191813115 |
boot floor plate |
|
| (12) |
191809074 |
carrier panel right 2 doors |
|
| (17) |
1H5813227 |
joint plate left |
|
| (18) |
1H5813228A |
joint plate right |
|
| (21) |
165813327 |
mounting for tail light left |
|
| (22) |
165813335 |
reinforcement for air duct left |
|
| (32) |
N 90231601 |
weld pin order unit 100 FD-5X25 |
|
| (6A) |
191803514C |
mounting for rear axle beam also use: right N 100 704 03 |
|
| (6A) |
191803513C |
mounting for rear axle beam also use: left N 100 704 03 |
|
| - |
165809440 |
filler plate rear panel upper part side panel, inner right right upper |
|
| - |
165809439 |
filler plate rear panel upper part side panel, inner left left upper |
|
| - |
N 10070403 |
hexagon head bolt c/w shoulder M10X30 |
|
| - |
N 90243001 |
seal 18X40 |
|
| - |
161253311 |
bracket for exhaust pipe |
|
| 10 |
191813120C |
carrier panel right lower |
|
| 11 |
191803477 |
reinforcement for jack socket |
|
| 12 |
191809073 |
carrier panel left 2 doors |
|
| 15 |
191803545 |
bracket for exhaust silencer |
|
| 16 |
191803531A |
cross member |
|
| 19 |
1H5813225 |
joint plate center |
|
| 1A |
1H0813141D |
seat support |
|
| 2 |
1H0803745 |
bracket for strap left rear |
|
| 20 |
165813301D |
rear apron |
|
| 20A |
191971926B |
grommet 33,5 |
|
| 21 |
165813328 |
mounting for tail light right |
|
| 22 |
165813336 |
reinforcement for air duct right |
|
| 23 |
165813514A |
parcel shelf, rear |
|
| 23A |
165813513B |
rear panel lower part |
|
| 24 |
165817127 |
water drain plate - lower part |
|
| 25 |
165817128 |
water drain plate - upper part |
|
| 26 |
411803595 |
cover 136MM |
|
| 27 |
N 90146604 |
cover plate 40 grey |
|
| 28 |
6X0803959 |
cover for sender unit |
|
| 29 |
321803963 |
seal |
|
| 2A |
191803746 |
bracket for strap right rear |
|
| 3 |
357803272 |
bracket for spare wheel |
|
| 30 |
N 0139655 |
oval head panel screw B4,2X9,5 |
|
| 31 |
N 10034401 |
plug C30 |
|
| 32 |
N 90175701 |
weld pin order unit 100 5X12 |
|
| 4 |
861803899B |
nut for spare wheel mounting |
|
| 5 |
191803503A |
longitudinal member left rear |
|
| 6 |
191803504A |
longitudinal member right rear |
|
| 7 |
165803491A |
connecting plate for longitudinal member left |
|
| 8 |
165803492B |
connecting plate for longitudinal member right |
|
| 9 |
191813119C |
carrier panel left lower |
|
