Оригинальный номер |
Название |
Заказ |
|
165827933A GRU |
primed |
|
(2) |
165827301 |
bonnet hinge left |
|
(21) |
191827573B |
lock cylinder for flap, rear for vehicles with central locking system |
|
(21) |
191827573A |
lock cylinder for flap, rear system b profile ah 1001-2000/3001-4000/6001-7086/ 8201-9282 for models without central locking |
|
(25) |
165827581C |
button for central locking system |
|
(43) |
165827933A |
spoiler |
|
- |
AKL44830004 |
protective foil 290X210MM left lower |
|
- |
N 0301191 |
oval head countersunk bolt for central locking system NM4X8 |
|
1 |
165827025A |
tailgate / boot lid |
|
11 |
191827499A |
stop buffer 30X22/12MM |
|
12 |
443827505 |
flap - lock inner |
|
13 |
311837943 |
concave spring washer 6,4X18 |
|
14 |
N 0141405 |
fillister hd. bolt M6X15 |
|
15 |
321827511A |
closure plate |
|
16 |
N 0141387 |
fillister hd. bolt M6X10 |
|
17 |
165827515 |
pull rod |
|
18 |
443827563A |
cover cap |
|
19 |
191837199 |
clip |
|
2 |
165827302 |
bonnet hinge right |
|
20 |
165827571F |
grip molding with lock cylinder for central locking system for models without central locking see parts bulletin: 8-144 3/1988 |
|
21 |
191827573 |
lock cylinder for flap, rear system a profile ah 1-1000/2001-3000/4001-6000/ 7101-8154 for models without central locking |
|
25 |
165827581B |
button for models without central locking |
|
26 |
165827584 |
expanding nut |
|
27 |
N 0116644 |
washer B4,3X12X1 |
|
28 |
N 0139649 |
oval head panel screw ST4,2X16-C |
|
29 |
165827592 |
expanding nut |
|
3 |
211805243 |
spring washer |
|
30 |
165827594 |
gasket |
|
31 |
165827596 |
spacer ring |
|
32 |
N 90098901 |
seal 18,5X2N |
|
33 |
111837227B |
seal |
|
34 |
N 90454501 |
lock washer 8 |
|
35A |
165827576A |
grip molding satin black |
|
36 |
321827589 |
pressure spring |
|
37 |
321827705A |
gasket shorten to: 3400MM |
|
4 |
N 01021226 |
hexagonal head bolt M6X12 |
|
40 |
321813998A |
insert nut 8X8MM |
|
41 |
171853919 |
sealing washer |
|
42 |
N 0139755 |
oval head panel screw ST4,8X19 |
|
43 |
165827933 |
spoiler black |
|
44 |
165827947A |
retainer |
|
45 |
N 90286703 |
hex. nut, self-locking with washer M6 |
|
46 |
191971908B |
plug 19,5 |
|
47 |
111837941 |
concave spring washer 6,4X12,5 |
|
48 |
N 0111165 |
hexagonal nut BM6 |
|
49 |
165827975 |
cover cap spoiler |
|
5 |
211513537 |
spring washer |
|
50 |
165827976 |
grommet |
|
51 |
N 0139694 |
oval head panel screw B4,8X16 |
|
6 |
N 90330101 |
allen key head bolt M8X23 |
|
7 |
165827349 |
tension spring |
|
8 |
113823355 |
protective pipe |
|
9 |
165827489 |
stop buffer |
|
